Установкa Thermo King ColdCube схема 37 GALLON ELECTRICAL COMPONENTS – 255E6
Обновление от: 1/20/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 42-247 | SWITCH - power, main | 2 | |
| 2 | 42-246 | CONTROLLER - 4 button | 1 | |
| 3 | 42-242 | RECTIFIER | 1 | |
| 4 | 41-226 | FUSE - 40 amp | 1 | |
|
10-41-226 | Предохранитель 40 ампер 10 шт | 1 860 ₽ |
|
| 5 | 42-243 | CORD - power, AC | 1 | |
| 6 | 42-264 | CORD - power, DC | 1 | |
| 7 | NSS | HOLDER - fuse | 1 | |
| 8 | 41-9454 | FUSE - 50 amp (freezing unit) | 1 | |
| 41-8075 | FUSE - 30 amp (cooling unit) | 1 | ||
| 9 | 40-1139 | KIT - relay (ignition, option) | 1 | |
| 10 | 42-260 | CONTROLLER - compressor (cooling unit) | 1 | |
| 42-261 | CONTROLLER - compressor (freezing unit) | 1 | ||
| 11 | 102-1033 | COMPRESSOR (cooling unit) | 1 | |
| 102-1034 | COMPRESSOR (freezing unit) | 1 | ||
| 12 | 44-9524 | FUSE - display (3 amp) | 1 | |
|
10-44-9524 | Предохранитель 3 ампер 10 шт | 1 860 ₽ |
|
| 13 | 42-263 | FAN | 1 | |
| 14 | 44-9344 | FUSE - 15 amp (cooling unit) | 1 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 41-1259 | FUSE - 25 amp (freezing unit) | 1 | ||
|
10-41-1259 | Предохранитель 25 ампер 10 шт | 1 860 ₽ |
|
