Установкa Thermo King X500 AP схема CONTROL PANEL – 260G9
Обновление от: 8/3/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-185 | PANEL - control | 1 | |
| 55-6994 | SCREW - panel | 7 | ||
| 55-6996 | LOCKWASHER | 11 | ||
| 55-7042 | NUT | 4 | ||
| 2 | 44-5537 | SOCKET - relay | 11 | |
| 55-5130 | RIVET - socket | 5 | ||
| 3 | 41-896 | RELAY - mini | 2 | |
| 4 | 44-9392 | RELAY - mini | 9 | |
| 5 | 41-3691 | COVER - fuse | 2 | |
| 6 | 41-3690 | HOLDER - fuse | 2 | |
| 55-2995 | SCREW - holder | 4 | ||
| 55-2964 | LOCKWASHER | 4 | ||
| 7 | 44-9524 | FUSE (3 amp) | 1 | |
|
10-44-9524 | Предохранитель 3 ампер 10 шт | 1 860 ₽ |
|
| 41-1292 | FUSE (5 amp) | 1 | ||
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 44-9344 | FUSE (15 amp) | 5 | ||
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 41-1259 | FUSE (25 amp) | 2 | ||
|
10-41-1259 | Предохранитель 25 ампер 10 шт | 1 860 ₽ |
|
| 8 | 305-1654 | SCREW (2) | 1 | |
| 55-448 | FLATWASHER | 2 | ||
| 55-8955 | WASHER | 3 | ||
| 55-8631 | WASHER - nylon | 1 | ||
| 55-8693 | WASHER - nylon | 1 | ||
| 55-3238 | LOCKWASHER | 2 | ||
| 305-1653 | NUT | 2 | ||
| 9 | 55-9191 | STUD (CH) | 1 | |
| 55-448 | FLATWASHER | 4 | ||
| 55-3672 | LOCKWASHER | 1 | ||
| 55-3066 | LOCKWASHER | 2 | ||
| 55-9189 | NUT | 4 | ||
| 10 | 92-449 | MARKSTRIP - 2 | 1 | |
| 11 | 92-450 | MARKSTRIP - CH | 1 | |
| 12 | 93-186 | MARKSTRIP - fuse | 1 | |
| 13 | 93-187 | MARKSTRIP - fuse | 1 | |
| 14 | 93-188 | MARKSTRIP - relay | 1 | |
| 15 | 93-189 | MARKSTRIP - relay | 1 |
