Установкa Thermo King TK6000 30 w/se 2.2 Engine схема REFRIGERATION COMPONENTS – 96B5
Обновление от: 4/26/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1175 | COIL - evaporator | 1 | |
| 2 | 66-7161 | TUBE - equalizer | 1 | |
| 3 | 66-7209 | VALVE - expansion (R134a, see 115B10) | 1 | |
| 66-9378 | SCREEN - inlet | 1 | ||
| 66-7979 | ELEMENT - power | 1 | ||
| 66-7162 | VALVE - expansion (R502, R402B, R403B, R404A, see 115B10) | 1 | ||
| 4 | 67-986 | HEAT EXCHANGER | 1 | |
| 91-5364 | INSULATION - heat exchanger | 2 | ||
| 5 | 66-7163 | TUBE | 1 | |
| 6 | 66-7164 | TUBE | 1 | |
| 7 | 66-7165 | TUBE | 1 | |
| 66-5752 | FITTING - tube | 1 | ||
| 8 | 66-7166 | TUBE | 1 | |
| 9 | 66-5824 | TUBE - defrost | 1 | |
| 99-6353 | CLAMP | 2 | ||
| 55-1587 | SCREW | 2 | ||
| 55-2699 | LOCKWASHER | 2 | ||
| 10 | 66-5787 | TUBE - receiver to dehydrator | 1 | |
| 11 | 61-600 | DEHYDRATOR (see 97A14) | 1 | |
|
US-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 6 880 ₽ |
|
| 10-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 3 420 ₽ |
|
|
|
PP-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 2 090 ₽ |
|
| 12 | 66-5753 | TUBE - drier to bulkhead | 1 | |
| 13 | 66-3858 | TUBE - 3-way to receiver tank | 1 | |
| 14 | 66-5780 | TUBE | 1 | |
| 15 | 66-7392 | VALVE - relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 33-1015 | O-RING | 1 | ||
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 16 | 66-5778 | TUBE - check valve | 1 | |
| 99-3060 | FITTING - saddle | 1 | ||
| 17 | 66-5721 | VALVE - check (1/2 od) | 1 | |
| 66-5721 OEM | Обратный клапан | 19 660 ₽ |
|
|
| 18 | 55-3094 | ELBOW | 1 | |
| 19 | 66-6621 | VIBRASORBER - suction | 1 | |
|
30-66-6621 | Трубка | 29 000 ₽ |
|
| 20 | 66-602 | ELBOW | 1 | |
| 21 | 66-4270 | ELBOW | 1 | |
| 22 | 66-3257 | ELBOW | 1 | |
| 23 | 67-1174 | TANK - accumulator (see 97A12) | 1 | |
| 67-1196 | TANK - accumulator (R134a only, see 97A12) | 1 | ||
| 24 | 99-978 | CLAMP - heat exchanger | 2 | |
| 25 | 66-5501 | VALVE - check | 1 | |
| 26 | 67-681 | COIL - condenser (see 97B1) | 1 | |
| 67-1176 | COIL - condenser (vinyl dip, see 97B1) | 1 | ||
| 27 | 99-1647 | BRACKET - discharge (before 6/95) | 1 | |
| 28 | N/A | COMPRESSOR (see 97A9) | 1 | |
| N/A | COMPRESSOR (R134a, R404A, see 124C11) | 1 | ||
| 29 | 66-5786 | TUBE - tee to bulkhead | 1 | |
| 30 | 55-5920 | U-BOLT (before 6/95) | 1 | |
| 55-431 | FLATWASHER | 2 | ||
| 55-5292 | NUT | 2 | ||
| 31 | 66-1332 | TUBE - discharge (before 6/95) | 1 | |
| 66-8057 | TUBE - discharge (after 6/95) | 1 | ||
| 32 | 66-8666 | VIBRASORBER - discharge | 1 | |
| 33 | 67-1179 | TANK - receiver (see 95B6) | 1 | |
| 34 | 66-4974 | VALVE - 3-way (see 115A10) | 1 | |
| 55-214 | SCREW - valve | 2 | ||
| 55-411 | FLATWASHER | 2 | ||
| 55-366 | LOCKWASHER | 2 | ||
| 35 | 66-7167 | TUBE - 3-way to solenoid | 1 | |
| 36 | 66-7207 | TUBE - valve to throttle | 1 | |
| 37 | 66-7636 | VALVE - pilot solenoid | 1 | |
|
10-66-7636 | Пилот соленоид с катушкой 12V, SB/SL/SLe/SLX/SLXe/SMX-II/V-Series | 33 380 ₽ |
|
|
PP-61-8938 | Пилот соленоид с катушкой 12V, SB/SL/SLe/SLX/SLXe/SMX-II/V-Series | 13 390 ₽ |
|
| 41-1521 | COIL | 1 | ||
|
10-41-1521 | Катушка соленоида, 12V 8W | 5 130 ₽ |
|
| 91-5457 | BRACKET - solenoid | 1 | ||
| 55-1384 | SCREW - valve | 2 | ||
| 55-5761 | LOCKWASHER | 2 | ||
| 55-406 | FLATWASHER | 2 | ||
| 38 | 55-6434 | TEE | 1 | |
| 39 | 66-7206 | HOSE | 1 | |
| 40 | 66-7168 | TUBE - valve to throttle (w/ compound gauge) | 1 | |
| 41 | 66-4346 | TEE | 1 | |
| 42 | 66-5330 | CONNECTOR - flare | 1 | |
| 43 | 66-4907 | GAUGE - compound | 1 | |
| 91-870 | LENS - gauge | 1 | ||
| 44 | 55-5607 | ADAPTER - flare | 1 | |
| 45 | 66-5825 | TUBE - defrost | 1 | |
| 46 | 66-7309 | TUBE - compound gauge | 1 | |
| 47 | 66-8057 | TUBE - discharge (6/95 & after) | 1 | |
| 48 | 91-6972 | BRACKET - discharge tube (6/95 & after) | 1 | |
| 49 | 91-6973 | CLAMP - discharge vibrasorber (6/95 & after) | 1 | |
| 55-145 | SCREW - clamp | 2 | ||
| 55-411 | FLATWASHER | 4 | ||
| 55-366 | LOCKWASHER | 2 | ||
| 55-291 | NUT | 2 |
