Установкa Thermo King T1-M17, M18, M19, M20, M20A, M20B схема COMPRESSOR GROUP (KIT 712764) – 96A13
Обновление от: 12/16/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-201 | SCREW - valve | 2 | |
| 55-895 | FLATWASHER | 2 | ||
| 2 | 33-2541 | GASKET - valve | 1 | |
| 3 | 66-2296 | CAP - service valve (plastic, incl gasket) | 2 | |
| P-17-10812-01 | Крышка сервисного клапана, пластик, 05K/05G/06D | 1 800 ₽ |
|
|
|
10-66-2296 | Крышка сервисного клапана, пластик, X426/430/640 | 1 800 ₽ |
|
| 33-3007 | GASKET - cap | 2 | ||
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 4 | 55-466 | ELBOW - suction valve | 1 | |
| 55-1983 | CAP - elbow | 1 | ||
| 33-768 | GASKET - cap | 1 | ||
| 5 | 33-2805 | GASKET - discharge valve & manifold | 3 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 6 | 22-749 | MANIFOLD - discharge | 1 | |
| 7 | 66-2140 | VALVE - discharge (incl 3) | 1 | |
| 8 | 55-308 | ELBOW - discharge valve | 1 | |
| 55-1983 | CAP - elbow | 1 | ||
| 33-768 | GASKET - cap | 1 | ||
| 9 | 55-459 | COUPLING | 1 | |
| 33-768 | GASKET - coupling | 1 | ||
| 10 | 44-7893 | SWITCH - lpco | 1 | |
| 44-6263 | SWITCH - only | 1 | ||
| 11 | 44-7814 | SWITCH - hpco | 1 | |
| 44-6265 | SWITCH - only | 1 | ||
| 12 | 44-7815 | DIODE | 1 | |
| 44-3940 | DIODE - only | 1 | ||
| 13 | 55-2381 | SCREW - suction adapter | 4 | |
| 55-896 | FLATWASHER | 4 | ||
| 14 | 55-5261 | CLAMP - harness | 2 | |
| 15 | 55-3674 | SCREW - valve | 2 | |
| 55-896 | FLATWASHER | 2 | ||
| 16 | 66-1896 | ADAPTER - suction valve | 1 | |
| 33-1221 | O-RING - adapter to compressor | 1 | ||
|
10-33-1221 | О-ринг под клапан - регулятор давления | 280 ₽ |
|
| 17 | 66-5758 | TUBE & VALVE - discharge (incl 3 & 7) | 1 | |
| 66-5760 | TUBE - discharge valve to elbow | 1 | ||
| 55-3310 | ELBOW | 1 | ||
| 55-3808 | ADAPTER - discharge tube | 1 | ||
| 18 | 33-594 | O-RING - adapter | 1 | |
| 19 | 66-5757 | TUBE & VALVE - suction (incl 3 & 20) | 1 | |
| 66-5759 | TUBE - suction valve to elbow | 1 | ||
| 55-3310 | ELBOW | 1 | ||
| 55-4185 | ADAPTER - suction tube | 1 | ||
| 20 | 66-3576 | VALVE - suction (incl 3) | 1 | |
| 21 | 33-544 | O-RING | 1 | |
| 22 | 22-738 | PLUG - compressor drain | 1 | |
| 55-1983 | CAP - valve drain plug | 1 | ||
| 23 | 107-192 | KIT - clutch drive repair (see 119B7) | 1 | |
| 24 | 102-913 | COMPRESSOR - X426 C5 (subassembly, see 231A2) | 1 | |
| 8102-913 | COMPRESSOR - X426 C5 (subassembly, reman, see 231A2) | 1 | ||
| 25 | 91-2506 | BRACKET - suction/discharge | 1 | |
| 26 | 55-5122 | U-BOLT - suction | 1 | |
| 55-4397 | U-BOLT - discharge | 1 | ||
| 27 | 55-4953 | NUT (1/4-20) | 6 | |
| 55-2086 | FLATWASHER (1/4) | 8 | ||
| 55-2977 | SCREW (1/4-20) | 1 | ||
| 28 | 55-3451 | STUD - clutch | 3 | |
| 55-790 | LOCKWASHER | 3 | ||
| 55-789 | NUT | 3 | ||
| 29 | 55-9088 | KEY | 1 | |
| 30 | 77-2498 | SPACER - clutch | 1 | |
|
10-77-2498 | Шайба муфты сцепления | 990 ₽ |
|
| 31 | 55-5283 | SCREW - clutch | 1 | |
| 32 | 55-6822 | SCREW - manifold | 4 | |
| 55-6804 | WASHER - sealing | 4 | ||
| 33 | 22-790 | PLATE - drive bearing | 1 | |
| 33-2513 | GASKET - plate | 1 | ||
|
10-33-2513 | Прокладка передней крышки, X418/426/430/640 | 1 450 ₽ |
|
| PP-33-2513 | Прокладка передней крышки, X418/426/430/640 | 500 ₽ |
|
|
| 34 | 55-2381 | SCREW - plate | 9 | |
| 55-896 | FLATWASHER | 9 | ||
| 35 | 22-751 | SEAL - crankshaft (stainless steel bellows) | 1 | |
| 36 | 91-2506 | BRACKET - u-bolt | 1 | |
| 55-3490 | SCREW - bracket | 2 | ||
| 55-399 | WASHER - spacer | 2 | ||
| 55-2958 | FLATWASHER | 2 | ||
| 55-4954 | NUT | 2 |
