Установкa Thermo King T-800R SPECTRUM EMEIA схема REMOTE EVAPORATOR GUARD – 235F6
Обновление от: 1/15/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 98-320 | GUARD - remote evaporator (S-3, see 197C4) | 1 | ||
| 98-319 | GUARD - remote evaporator (S-2, see 197C4) | 1 | ||
| 98-320 | GUARD - remote evaporator (S-3, see 197C4) | 1 | ||
| 98-319 | GUARD - remote evaporator (S-2, see 197C4) | 1 | ||
| 1 | 92-7587 | MEMBER - side (aluminum) | 2 | |
| 92-7621 | MEMBER - side (stainless steel) | 2 | ||
| 2 | 92-7590 | BEAM - cross (S-3, aluminum) | 4 | |
| 92-7622 | BEAM - cross (S-3, stainless steel) | 4 | ||
| 92-7588 | BEAM - cross (S-2, aluminum) | 4 | ||
| 92-7623 | BEAM - cross (S-2, stainless steel) | 4 | ||
| 51-271 | SCREW - cross beam | 8 | ||
| 3 | 92-7589 | CORNERPLATE - roof | 4 | |
| 4 | 55-5005 | SCREW - corner plate | 4 | |
| 51-137 | WASHER | 4 |
