Установкa Thermo King T-500R EMEIA схема BELTS, PULLEYS & FAN GROUP – 259E0
Обновление от: 1/30/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 78-1802 | BELT - engine to motor/jackshaft | 1 | |
| PP-78-1802 | Ремень двигатель - электромотор, T-500R | 5 430 ₽ |
|
|
| 2 | 107-349 | CLUTCH (see 145F4) | 1 | |
|
10-107-349 | Сцепление, MD/RD/KD/T-Series | 98 400 ₽ |
|
|
PP-107-349 | Сцепление, MD/RD/KD/T-Series | 46 200 ₽ |
|
| 55-5022 | SCREW - clutch | 6 | ||
| 55-7727 | LOCKWASHER | 6 | ||
| 3 | 77-3060 | PULLEY - idler (see 259E3) | 1 | |
|
10-77-3060 | Ролик приводного ремня, T-500 | 5 650 ₽ |
|
| 4 | 77-3051 | PULLEY - motor/jackshaft | 1 | |
| 55-9724 | SCREW - pulley | 2 | ||
| 55-7727 | LOCKWASHER | 2 | ||
| 5 | 78-1822 | BELT - motor/jackshaft to compressor | 1 | |
| 78-1822 OEM | Ремень компрессора, T-5ХХ/6ХХ/8ХХ | 7 650 ₽ |
|
|
| PP-78-1822 | Ремень компрессора, T-5ХХ/6ХХ/8ХХ | 1 420 ₽ |
|
|
| 6 | 77-2964 | PULLEY - alternator | 1 | |
| 7 | 45-2500 | ALTERNATOR (65 amp) | 1 | |
| 8 | 77-3061 | PULLEY - idler | 1 | |
| 55-5419 | SCREW - pulley | 1 | ||
| 55-7347 | LOCKWASHER | 1 | ||
| 9 | 77-3050 | PULLEY - compressor | 1 | |
| 10 | 77-2537 | BUSHING - compressor pulley | 1 | |
| 55-3121 | SCREW - bushing | 3 | ||
| 55-1800 | LOCKWASHER | 3 | ||
| 11 | 55-455 | KEY - compressor pulley | 1 | |
|
10-55-455 | Шпонка коленвала, D214/X214 | 290 ₽ |
|
| 12 | 102-1072 | COMPRESSOR - X214 (see 185H5) | 1 | |
| 13 | 104-801 | MOTOR - 7.2 hp (see 259D0) | 1 | |
| 14 | 78-1695 | JACKSHAFT (see 259E2) | 1 | |
| 15 | 55-3264 | KEY - square (fan) | 1 | |
| 55-3263 | KEY - square (pulley) | 1 | ||
| 16 | 77-1699 | HUB - fan | 1 | |
| 55-8650 | SCREW - hub to shaft | 2 | ||
| 55-790 | LOCKWASHER | 2 | ||
| 55-895 | FLATWASHER | 2 | ||
| 17 | 78-1403 | FAN - condenser | 1 | |
| 55-141 | SCREW - fan to hub | 4 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 18 | 78-1492 | BELT - water pump (see 209A6 ) | 1 | |
| 10-78-1492 | Ремень водяного насоса, Yanmar TK 370, T-600/800 | 2 820 ₽ |
|
|
|
PP-78-1492 | Ремень водяного насоса, Yanmar TK 370, T-600/800 | 980 ₽ |
|
| 19 | 98-8931 | PLENUM - condenser fan | 1 | |
| 20 | 92-7535 | POCKET - plenum | 1 | |
| 51-1602 | RIVET - pocket | 4 | ||
| 55-9975 | CLIP - retaining | 2 | ||
| 51-1840 | RIVET - clip | 2 | ||
| 21 | 92-9592 | ORIFICE - condenser fan | 1 | |
| 55-6994 | SCREW - orifice | 2 | ||
| 55-3045 | WASHER - dome | 2 | ||
| 55-8849 | NUT - captive | 2 |
