Установкa Thermo King Super-II 30 MAX w/se 2.2 Engine схема CONTROL BOX COVER (50s) – 112D6
Обновление от: 11/27/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-4392 | PANEL - control box | 1 | |
| 2 | 44-7054 | TERMINAL - bulb | 8 | |
| 3 | 44-6462 | SOCKET - bulb | 4 | |
| 4 | 44-3711 | BULB - light | 4 | |
| 5 | 41-165 | HARNESS - diesel/electric switch | 1 | |
| 44-5718 | CONNECTOR (8-pin, male) | 1 | ||
| 44-5719 | CONNECTOR (8-pin, female) | 1 | ||
| 44-7872 | CONNECTOR - tower (6-pin) | 1 | ||
| 6 | 44-490 | SWITCH - diesel/electric (2 pole) | 1 | |
|
10-44-490 | Выключатель | 2 590 ₽ |
|
| 7 | 44-709 | SWITCH - diesel/electric (4pdt) | 1 | |
|
10-44-709 | Выключатель четырехполюсный | 5 130 ₽ |
|
| 8 | 91-944 | NAMEPLATE - Indicator Lights | 1 | |
| 9 | 44-5234 | SENSOR - thermometer/thermostat | 2 | |
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 10 | 45-1579 | THERMOSTAT - TG V | 2 | |
| 92-6219 | FACEPLATE - TG V (includes 91-4642 overlay) | 1 | ||
| 91-4642 | OVERLAY - TG V (transparent) | 1 | ||
| 91-4236 | NAMEPLATE - TG V Setup Codes | 2 | ||
| 55-4370 | SCREW - thermostat & cover | 8 | ||
| 11 | 91-2674 | COVER - thermostat | 1 | |
|
10-91-2674 | Крышка термостата | 9 200 ₽ |
|
| 33-2145 | GASKET - cover | 1 | ||
| 33-2128 | GASKET - thermostat | 1 | ||
| 12 | 91-3485 | NAMEPLATE - coolant | 1 | |
| 13 | 44-9259 | HOURMETER (analog) | 2 | |
|
10-44-9259 | Счетчик часов | 6 400 ₽ |
|
| 41-3450 | HOURMETER (digital) | 1 | ||
| 14 | 91-1135 | NAMEPLATE - Cover Screw Torque | 1 | |
| 15 | 91-943 | NAMEPLATE - Cool/Defrost/Heat (Front Evaporator) | 1 | |
| 91-3486 | MARKSTRIP | 1 | ||
| 16 | 44-8017 | DETECTOR - liquid level | 1 | |
| 55-3256 | SCREW - detector | 2 | ||
| 55-3013 | FLATWASHER | 2 | ||
| 55-3014 | LOCKWASHER | 2 | ||
| 17 | 45-1470 | PANEL - switch (w/o Cycle Sentry, see 100D9) | 1 | |
| 45-1473 | PANEL - switch (w/ Cycle Sentry, see 102G2) | 1 | ||
| 55-6352 | SCREW - panel (1.0 in lg) | 2 | ||
| 55-6353 | SCREW - panel (2.0 in lg) | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-4953 | NUT | 2 | ||
| 18 | 44-7330 | CONNECTOR - shroud (1-pin) | 1 | |
| 44-5883 | TERMINAL - male (18-20 ga) | 2 | ||
| 19 | 44-1458 | JUMPER | 3 | |
| 91-3488 | NAMEPLATE | 1 | ||
| 55-2086 | FLATWASHER | 6 | ||
| 55-1800 | LOCKWASHER | 12 | ||
| 20 | 91-497 | NAMEPLATE - electric | 2 | |
| 21 | 91-498 | NAMEPLATE - engine | 2 | |
| 22 | 91-499 | ROD - gang | 1 | |
| 23 | 55-5202 | SCREW - set | 2 |
