Установкa Thermo King SPECTRUM SB TCI схема RECEIVER TANK – 185B4
Обновление от: 3/20/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2653 | TANK - receiver | 1 | |
| 2 | 33-2419 | O-RING | 1 | |
| 3 | 66-9918 | INDICATOR - liquid | 1 | |
| 66-9257 | BALL | 1 | ||
| 4 | 66-343 | CAP - valve | 2 | |
| 55-581 | WASHER (copper) | 2 | ||
| 55-5078 | NUT - tank | 2 | ||
| 51-192 | WASHER - special | 2 | ||
| 5 | 92-2944 | BRACKET - bottom | 1 | |
| 55-4967 | NUT - bracket | 2 | ||
| 55-371 | FLATWASHER | 2 | ||
| 6 | 33-1015 | O-RING | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 7 | 66-7392 | VALVE - relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 8 | 61-2193 | TUBE - check valve to receiver | 1 | |
| 9 | 66-5721 | VALVE - check | 1 | |
| 66-5721 OEM | Обратный клапан | 19 660 ₽ |
|
|
| 10 | 61-3633 | TUBE - cond to check valve | 1 | |
| 11 | 61-2195 | TUBE - purge valve to cond | 1 | |
| 12 | 61-2196 | TUBE - receiver to dehydrator | 1 | |
| 13 | 61-600 | DEHYDRATOR (see 160A4) | 1 | |
|
US-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 8 100 ₽ |
|
|
PP-61-600 | Дегидратор, SL/SLe/SLX/SLXe/SMX/SMX-II/SB / UT-800/1200 | 2 490 ₽ |
|
| 14 | 61-2197 | TUBE - RTPS to receiver | 1 |
