Установкa Thermo King SL-300 схема NAMEPLATES – 149G3
Обновление от: 4/6/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-8341 | NAMEPLATE - TK Logo (8.5 x 9.5) | 1 | |
| 91-8342 | NAMEPLATE - TK Logo (3.0 x 3.4) | 1 | ||
| 2 | 91-8746 | NAMEPLATE - Ingersoll Rand (black letters) | 1 | |
| 91-9043 | NAMEPLATE - Ingersoll Rand (white letters) | 1 | ||
| 3 | 91-4077 | NAMEPLATE - Smart Reefer (black letters) | 1 | |
| 4 | 91-2658 | NAMEPLATE - Smart Reefer (white letters) | 1 | |
| 5 | 91-8280 | NAMEPLATE - Thermo King (chrome letters) | 1 | |
| 6 | 91-8279 | NAMEPLATE - Thermo King (black letters) | 1 | |
| 7 | 91-9581 | NAMEPLATE - Caution | 1 | |
| 8 | 91-8281 | NAMEPLATE - WHISPER Edition | 1 | |
| 9 | 91-9031 | NAMEPLATE - SL-300 SR (black letters) | 2 | |
| 10 | 91-9030 | NAMEPLATE - SL-300 SR (white letters) | 2 | |
| 11 | 91-4583 | NAMEPLATE - modulation | 1 | |
| 12 | 91-3014 | NAMEPLATE - Warning Engine Overspeed 1600 RPM | 1 | |
| 91-7985 | NAMEPLATE - Warning Engine Overspeed 2200 RPM | 1 | ||
| 13 | 99-8508 | NAMEPLATE - Caution | 1 | |
| 14 | 99-9854 | NAMEPLATE - Caution (multi-language) | 1 | |
| 15 | 99-9084 | NAMEPLATE - arrow | 1 | |
| 16 | 91-7986 | NAMEPLATE - High/Low Speed (1600/1200) | 1 | |
| 17 | 99-9938 | NAMEPLATE - Caution, Start/Stop | 1 | |
| 18 | 91-3471 | NAMEPLATE - See Operating Instructions | 1 | |
| 19 | 91-6835 | NAMEPLATE - Factory Settings | 1 | |
| 20 | 91-7206 | NAMEPLATE - Tag, Caution Before Starting | 1 | |
| 21 | 91-9033 | NAMEPLATE - High/Low Speed 2200 RPM | 1 | |
| 22 | 99-9939 | NAMEPLATE - Caution, Start/Stop (multi-language) | 1 | |
| 23 | 99-8506 | NAMEPLATE - Caution, Fan | 1 | |
| 24 | 99-8507 | NAMEPLATE - Caution, Fan (multi-language) | 1 | |
| 25 | 99-7834 | NAMEPLATE - Caution | 1 | |
| 26 | 91-3014 | NAMEPLATE - Warning Engine Overspeed 1600 RPM | 1 | |
| 27 | 91-5887 | NAMEPLATE - Compressor Oil 67-404 | 1 | |
| 28 | 99-9940 | NAMEPLATE - Caution | 1 | |
| 29 | 91-4193 | NAMEPLATE - Motorized Damper Blade | 1 | |
| 30 | 91-8271 | NAMEPLATE - See Operating Instructions | 1 | |
| 31 | 92-324 | NAMEPLATE - Compressor Oil 203-513 | 1 | |
| 32 | 91-5886 | NAMEPLATE - Refrigerant R404A | 1 | |
| 33 | 91-5882 | NAMEPLATE - R404A | 1 | |
| 34 | 99-9941 | NAMEPLATE - Caution, Cycle Sentry | 1 | |
| 35 | 99-8421 | NAMEPLATE - Caution, High Voltage | 1 | |
| 36 | 99-9856 | NAMEPLATE - Caution, High Voltage (multi-language) | 1 | |
| 37 | 99-8509 | NAMEPLATE - Maintenance | 1 | |
| 38 | 91-8067 | NAMEPLATE - TG mP IV+ Alarm Codes | 1 |
