Установкa Thermo King NSD-II схема COMPRESSOR GROUP (KIT 713921) – 105A14
Обновление от: 8/19/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 55-201 | SCREW - valve | 2 | |
| 55-895 | FLATWASHER | 2 | ||
| 2 | 33-2541 | GASKET - valve | 1 | |
| 3 | 66-2296 | CAP - service valve (plastic, incl gasket) | 2 | |
| P-17-10812-01 | Крышка сервисного клапана, пластик, 05K/05G/06D | 1 800 ₽ |
|
|
|
10-66-2296 | Крышка сервисного клапана, пластик, X426/430/640 | 1 800 ₽ |
|
| 33-3007 | GASKET - cap | 2 | ||
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 4 | 55-466 | ELBOW - suction valve | 1 | |
| 55-1983 | CAP - elbow | 1 | ||
| 33-768 | GASKET - cap | 1 | ||
| 5 | 33-2805 | GASKET - discharge valve & manifold | 3 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 6 | 22-660 | MANIFOLD - discharge | 1 | |
|
10-22-660 | Коллектор компрессора X430 | 29 550 ₽ |
|
| 55-3364 | PLUG - pipe | 3 | ||
| 7 | 66-2140 | VALVE - discharge (incl 3) | 1 | |
| 8 | 55-308 | ELBOW | 2 | |
| 55-1983 | CAP - elbow | 1 | ||
| 33-768 | GASKET - cap | 1 | ||
| 9 | 55-1653 | ELBOW | 1 | |
| 33-768 | GASKET - coupling | 1 | ||
| 10 | 44-7814 | SWITCH - hpco (450 psi) | 1 | |
| 44-6265 | SWITCH - only | 1 | ||
| 11 | 44-8734 | SWITCH - lpco (5 psi) | 1 | |
| 44-4258 | SWITCH - only | 1 | ||
| 12 | 44-7815 | DIODE | 1 | |
| 44-3940 | DIODE - only | 1 | ||
| 55-2996 | LOCKWASHER | 1 | ||
| 13 | 55-2306 | SCREW - manifold | 4 | |
| 30-55-2306 | Болт 3/8x1 5/8 | 680 ₽ |
|
|
| 55-896 | FLATWASHER | 4 | ||
| 14 | 22-778 | SEAL - crankshaft | 1 | |
| 22-778 OEM | Сальник коленвала, X418/X426/X430 | 14 860 ₽ |
|
|
|
10-22-778 | Сальник коленвала, X418/X426/X430 | 11 920 ₽ |
|
|
PP-22-778 | Сальник коленвала, X418/X426/X430 | 2 720 ₽ |
|
| 15 | 55-6776 | SCREW - valve | 2 | |
| 55-6804 | WASHER - special | 2 | ||
| 16 | 66-1896 | ADAPTER - suction valve | 1 | |
| 17 | 66-3576 | VALVE - suction (incl 3) | 1 | |
| 18 | 55-9088 | KEY - shaft (1.5 in lg) | 1 | |
| 19 | 77-2498 | SPACER - clutch | 1 | |
|
10-77-2498 | Шайба муфты сцепления | 990 ₽ |
|
| 20 | 55-5283 | SCREW - clutch | 1 | |
| 21 | 55-5261 | CLAMP - harness | 3 | |
| 22 | 11-2886 | VALVE (Schrader) | 1 | |
| 55-1983 | CAP - valve | 1 | ||
| 11-7777 | CORE | 1 | ||
| 23 | See Note | CLUTCH (24VDC, see 94G5) | 1 | |
| 77-1663 | PULLEY (2-B/2-A grooves, 7.75/8.9 in od) | 1 | ||
| 24 | 8102-914 | COMPRESSOR - X430 SS C5 (dry new exchange, see 231C2) | 1 | |
| 25 | 22-754 | PLATE - drive bearing | 1 | |
| 33-2513 | GASKET - plate | 1 | ||
|
10-33-2513 | Прокладка передней крышки, X418/426/430/640 | 1 450 ₽ |
|
| PP-33-2513 | Прокладка передней крышки, X418/426/430/640 | 500 ₽ |
|
|
| 26 | 55-2381 | SCREW - plate | 9 | |
| 55-896 | FLATWASHER | 9 | ||
| 27 | 44-9541 | HARNESS - compressor | 1 | |
| 44-9569 | CONNECTOR - shroud (3-pin) | 1 | ||
| 44-7330 | CONNECTOR - shroud (1-pin) | 1 | ||
| 44-7327 | CONNECTOR - tower (1-pin) | 1 | ||
| 28 | 55-3451 | STUD - clutch | 3 | |
| 55-790 | LOCKWASHER | 3 | ||
| 55-789 | NUT | 3 | ||
| 29 | 33-2120 | SEAL | 1 | |
| 10-33-2120 | Сальник крышки компрессора X426/430/640 | 1 690 ₽ |
|
|
| PP-33-2120 | Сальник крышки компрессора X426/430/640 | 480 ₽ |
|
