Установкa Thermo King MD-MT схема ELECTRICAL COMPONENTS (MD-II TLE) – 180H4
Обновление от: 10/11/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | BOX - remote control (see 120E13) | 1 | |
| 2 | 44-9199 | CABLE - power | 1 | |
| 3 | 44-9245 | HARNESS - remote | 1 | |
| 4 | 41-624 | HARNESS - remote box (common) | 1 | |
| 5 | 66-4907 | GAUGE - compound (optional) | 1 | |
| 91-870 | LENS - gauge | 1 | ||
| 66-4346 | TEE - gauge | 1 | ||
| 66-6965 | TUBE - gauge | 1 | ||
| 55-328 | ELBOW | 1 | ||
| 6 | 44-9259 | HOURMETER (analog) | 1 | |
|
10-44-9259 | Счетчик часов | 6 400 ₽ |
|
| 41-3450 | HOURMETER (digital) | 1 | ||
| 7 | NSS | BOX - control (see 120E12) | 1 | |
| 8 | 104-774 | MOTOR - electric (see 126F4) | 1 | |
| 9 | 99-9700 | NAMEPLATE - 380VAC 50 Hz, 3 phase | 1 | |
| 55-2789 | FITTING - connector | 1 | ||
| 55-2635 | NUT | 1 | ||
| 10 | 41-2196 | ALTERNATOR (65 amp, see 144C2) | 1 | |
|
10-41-2196 | Генератор 65A, KD/MD/RD/TD-II / URD / SB-II/III | 22 650 ₽ |
|
| 11 | 44-9107 | HARNESS - alternator | 1 | |
| 12 | 41-3846 | SWITCH - hpco (450 psi, green) | 1 | |
| 13 | 44-8199 | SWITCH - hpco (200 psi, yellow) | 1 | |
| 14 | 45-1718 | STARTER (see 76C11) | 1 | |
|
10-45-1718 | Стартер, Yanmar 366 / 374 / 388 / 395 | 12 860 ₽ |
|
| 45-2326 | STARTER (standard life plus) | 1 | ||
| 15 | 41-3923 | HARNESS - main | 1 | |
| 16 | 41-3921 | CABLE - battery to post | 1 | |
| 17 | 44-8430 | CABLE - terminal | 1 | |
| 18 | 66-5305 | VALVE - solenoid (defrost, see 116G10) | 1 | |
| 19 | 66-8556 | VALVE - solenoid (suction) | 1 | |
| 60-231 | COIL - valve | 1 | ||
| 20 | 66-5306 | VALVE - solenoid (suction, see 138A6) | 1 | |
| 21 | 33-629 | GROMMET (1.0 id) | 2 | |
| 33-1770 | GROMMET (1.50 id) | 2 | ||
| 33-572 | GROMMET (0.75 id) | 2 | ||
| 33-489 | GROMMET (1.25 id) | 2 | ||
| 33-623 | GROMMET (2.125 id) | 2 | ||
| 33-1371 | GROMMET (1.70 id) | 3 | ||
| 22 | 40-805 | KIT - battery fuse (see 161G6) | 1 | |
|
10-40-805 | Корпус предохранителя (60 ампер) | 7 860 ₽ |
|
| 41-3666 | FUSE (60 amp) | 1 | ||
| 55-2965 | NUT | 10 | ||
| 23 | 44-9181 | SOLENOID - fuel (see 109G2) | 1 | |
|
10-44-9181 | Соленоид оборотов двигателя | 22 340 ₽ |
|
| 10-41-1566 | Соленоид оборотов двигателя в сборе | 19 600 ₽ |
|
|
|
PP-44-9181 | Соленоид оборотов двигателя в сборе | 6 870 ₽ |
|
| 24 | 41-1972 | HARNESS - fuel solenoid | 1 | |
| 25 | 55-2961 | SCREW - terminal (see 161G6) | 2 | |
| 55-2641 | FLATWASHER | 4 | ||
| 55-3471 | LOCKWASHER | 3 | ||
| 55-3300 | NUT - jam | 2 | ||
| 26 | 44-3018 | SWITCH - water temperature | 1 | |
|
10-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 5 330 ₽ |
|
| PP-44-3018 | Датчик температуры двигателя, Yanmar / Isuzu | 2 200 ₽ |
|
|
| 27 | 41-6865 | SWITCH - oil pressure | 1 | |
|
10-41-6865 | Сенсор давления масла, Yanmar, кроме 370 / 376 | 9 310 ₽ |
|
| PP-41-6865 | Сенсор давления масла, Yanmar, кроме 370 / 376 | 2 720 ₽ |
|
|
| 28 | 41-6582 | GLOW PLUG | 3 | |
|
10-41-6582 | Свеча накаливания, Yanmar 249 / 366 / 374 / 388 / 395 | 2 470 ₽ |
|
|
10-42-916 | Свеча накаливания, Yanmar 370 / 376 | 2 340 ₽ |
|
| PP-41-6582 | Свеча накаливания, Yanmar 249 / 366 / 374 / 388 / 395 | 1 190 ₽ |
|
|
| PP-42-916 | Свеча накаливания, Yanmar 370 / 376 | 1 190 ₽ |
|
|
| 29 | 44-7129 | CONNECTOR - glow plug | 1 | |
| 30 | 44-7186 | CABLE - ground (terminal to engine bracket) | 1 | |
| 31 | 41-4946 | HARNESS - junction evaporator (incl item 34) | 1 | |
| 32 | 44-5814 | CONNECTOR (4-pin, female) | 1 | |
| 33 | 44-5600 | CONNECTOR (6-pin, male) | 1 | |
| 34 | 44-9089 | CONNECTOR (24-pin) | 1 | |
| 35 | 41-1201 | GAUGE - water temperature (option) | 1 | |
| 36 | 44-3258 | AMMETER (optional) | 1 | |
| 44-3258 OEM | Амперметр, KD/MD/RD/TD-II / SB-II/III | 2 400 ₽ |
|
|
| 37 | 44-7485 | GAUGE - oil pressure (optional) | 1 | |
|
10-44-7485 | Датчик давления масла | 4 800 ₽ |
|
| 38 | 92-797 | BRACKET - plug | 1 | |
| 55-5638 | SCREW - bracket | 4 |
