Установкa Thermo King LRV-10T PCC схема CONDENSER COVERS – 184C6
Обновление от: 5/23/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-6600 | COVER - right | 1 | |
| 2 | 98-6601 | COVER - left | 1 | |
| 55-9368 | SCREW - cover & grille | 12 | ||
| 55-5970 | WASHER - sealing | 12 | ||
| 3 | 98-6331 | COVER - center | 1 | |
| 55-9368 | SCREW - cover & grille | 8 | ||
| 51-871 | WASHER - sealing | 8 | ||
| 4 | 309-3229 | GRILLE - inlet | 2 | |
| 55-9368 | SCREW - cover & grille | 12 | ||
| 55-5970 | WASHER - sealing | 12 | ||
| 5 | 309-3224 | GRILLE - fan (outlet) | 2 | |
| 55-9368 | SCREW - fan to grille | 12 | ||
| 55-8893 | FLATWASHER | 12 | ||
| 55-9553 | NUT - captive | 12 | ||
| 6 | 98-7766 | CAP - end | 1 | |
| 55-8837 | SCREW - cap (M6 x 25) | 2 | ||
| 51-871 | WASHER - sealing | 2 | ||
| 55-9368 | SCREW - cap (M6 x 20) | 6 | ||
| 55-6994 | SCREW - cap (M6) | 2 | ||
| 55-5970 | WASHER - sealing | 8 | ||
| 55-9553 | NUT - captive (M6) | 8 | ||
| 55-6997 | NUT - captive (M6) | 2 | ||
| 7 | 92-2026 | BRACKET - cap | 1 | |
| 8 | 92-2027 | BRACKET - cap | 1 | |
| 55-6994 | SCREW - bracket | 6 | ||
| 55-6996 | LOCKWASHER | 6 | ||
| 55-7075 | FLATWASHER | 6 | ||
| 55-9553 | NUT - captive | 6 | ||
| 9 | 92-2868 | HOLDER - cap (side) | 2 | |
| 10 | 92-2869 | HOLDER - cap (center) | 1 | |
| 11 | 92-2870 | HOLDER - cap (side) | 2 | |
| 12 | 92-2871 | HOLDER - cap (center) | 1 | |
| 55-6994 | SCREW - holder | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 8 | ||
| 55-9553 | NUT - captive | 8 | ||
| 13 | 92-1995 | CLIP - cap (right) | 1 | |
| 14 | 92-1996 | CLIP - cap (left) | 1 | |
| 55-6994 | SCREW - clip | 2 | ||
| 55-6996 | LOCKWASHER | 2 | ||
| 55-8893 | FLATWASHER | 2 | ||
| 15 | 99-4931 | NAMEPLATE - Arrow | 2 | |
| 16 | 309-3064 | NAMEPLATE - No Step | 1 | |
| 17 | 92-2823 | NAMEPLATE - Lifting | 2 | |
| 18 | 99-7834 | NAMEPLATE - Caution | 1 | |
| 19 | 92-1307 | NAMEPLATE - IR Logo | 2 | |
| 20 | 99-8506 | NAMEPLATE - Caution Fan | 1 | |
| 21 | 99-4976 | STRIP - neoprene (0.12 thick x .5 wide) | A/R | |
| 22 | 92-2302 | STRIP - neoprene (0.06 thick x .4 wide) | A/R | |
| 23 | 99-7336 | STRIP - neoprene (0.12 x 0.8 x 50 ft) | A/R |
