Установкa Thermo King KRS Plus схема HARNESS CONDENSER (78-1529 fans) – 232G9
Обновление от: 12/17/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-8491 | HARNESS - condenser (brushless fans) | 1 | |
| 2 | 41-4054 | CONNECTOR - male (10-pin) | 1 | |
| 41-2779 | PIN - male (18 ga) | 4 | ||
| 41-2785 | PIN - male (14 ga) | 6 | ||
| 3 | 44-5835 | CONNECTOR - shroud (2-pin, see 115D14) | 1 | |
| 4 | 44-6959 | CONNECTOR - tower (3-pin) | 4 | |
| 5 | 44-5838 | CONNECTOR - tower (2-pin) | 1 |
