Установкa Thermo King F-2 to F-5 Eutectic схема REFRIGERATION COMPONENTS - NOSEMOUNT – 144C12
Обновление от: 8/13/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-642 | COMPRESSOR (F-2 R404A, 380/3/50) | 1 | |
| 30-229 | KIT - compressor gaskets (F-2) | 1 | ||
| 102-641 | COMPRESSOR (F-3 R404A, 380/3/50) | 1 | ||
| 102-753 | COMPRESSOR (F-3 R404A 230-400/3/60) | 1 | ||
| 30-229 | KIT - compressor gaskets (F-3) | 1 | ||
| 104-689 | COMPRESSOR (F-4 R404A, 380/3/50) | 1 | ||
| 102-754 | COMPRESSOR (F-4 R404A, 230-400/3/60) | 1 | ||
| 30-230 | KIT - compressor gaskets (F-4) | 1 | ||
| 102-640 | COMPRESSOR (F-5 R404A 380/3/50) | 1 | ||
| 102-755 | COMPRESSOR (F-5 R404A 230-400/3/60) | 1 | ||
| 30-228 | KIT - compressor gaskets (F-5) | 1 | ||
| 203-513 | OIL - compressor | A/R | ||
| EN-203-513 | Масло компрессора, R134a / R404a | 2 200 ₽ |
|
|
| 41-901 | MODULE - control | 1 | ||
| 2 | 22-972 | VALVE - discharge (for compressor 102-642) | 1 | |
| 3 | 22-973 | VALVE - suction (for compressor 102-642) | 1 | |
| 22-972 | VALVE - discharge (for compressor 102-641 & 102-753) | 1 | ||
| 22-971 | VALVE - suction (for compressor 102-641 & 102-753) | 1 | ||
| 22-975 | VALVE - discharge (for compressor 102-639 & 102-754) | 1 | ||
| 22-970 | VALVE - suction (for compressor 102-639 & 102-754) | 1 | ||
| 22-974 | VALVE - discharge (for compressor 102-640 & 102-755) | 1 | ||
| 22-969 | VALVE - suction (for compressor 102-640 & 102-755) | 1 | ||
| 4 | 55-9001 | PLUG - fusible | 1 | |
| 5 | 67-1243 | COIL - condenser (F-3, F-4 & F-5) | 1 | |
| 67-1265 | COIL - condenser (F-2) | 1 | ||
| 6 | 41-1676 | COIL - valve (50 Hz) | 1 | |
| 41-3287 | COIL - valve (60 Hz) | 1 | ||
| 7 | 66-7688 | BASE - solenoid valve (3/8 in, F-2 & F-3) | 1 | |
| 66-7686 | BASE - solenoid valve (1/2 in, F-4 & F-5) | 1 | ||
| 8 | 91-8490 | BRACKET - solenoid valve | 1 | |
| 9 | 66-7676 | INDICATOR - liquid (1/2 in, F-4 & F-5) | 1 | |
| 61-5144 | INDICATOR - liquid (#6, F-3 & F-2) | 1 | ||
| 10 | 91-6408 | HANGER - filter | 1 | |
| 11 | 91-8491 | SUPPORT - clamp | 1 | |
| 12 | 91-8492 | BRACKET - tube support | 1 | |
| 13 | 91-8493 | SUPPORT - tube | 1 | |
| 14 | 91-8494 | SUPPORT - tube | 1 | |
| 15 | 55-8997 | SPACER - compressor | 4 | |
| 51-173 | SPACER - compressor (F-2) | 4 | ||
| 55-8999 | SCREW - compressor | 4 | ||
| 55-8536 | WASHER | 8 | ||
| 55-5025 | NUT | 4 | ||
| 16 | 66-8472 | DEHYDRATOR (#8, F-4 & F-5) | 1 | |
| 66-8471 | DEHYDRATOR (#6, F-3) | 1 | ||
|
14-00326-03 OEM | Дегидратор, Supra/Xarios/Citimax | 5 870 ₽ |
|
|
P-14-00326-03 | Дегидратор, Supra/Xarios/Citimax | 2 820 ₽ |
|
|
PP-14-00326-03 | Дегидратор, Supra/Xarios/Citimax | 1 300 ₽ |
|
| 66-8718 | DEHYDRATOR (#6, F-2) | 1 | ||
|
14-00326-04 OEM | Дегидратор, Xarios / Zephyr | 4 340 ₽ |
|
|
P-14-00326-04 | Дегидратор, Xarios / Zephyr | 4 080 ₽ |
|
| PP-14-00326-04 | Дегидратор, Xarios / Zephyr | 2 350 ₽ |
|
|
| 17 | 33-566 | O-RING - dehydrator (#8, F-4 & F-5) | 2 | |
| 33-1015 | O-RING - dehydrator (#6, F-2 & F-3) | 2 | ||
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 61-469 | NUT - adapter (#8, o-ring seal) | 2 | ||
| 55-9009 | NUT (#6, o-ring seal) | 2 | ||
| 61-470 | SHOULDER - o-ring seal (#8) | 2 | ||
| 55-9286 | SHOULDER (#8, o-ring seal) | 2 | ||
| 18 | 67-1261 | TANK - receiver | 1 | |
| 19 | 66-9005 | VALVE - high pressure relief | 1 | |
| 33-1015 | O-RING - valve | 1 | ||
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 20 | 41-918 | SWITCH - pressure | 1 | |
| 21 | 91-6382 | BRACKET - switch | 1 | |
| 22 | 22-954 | VALVE - pressure regulator (F-2 & F-3) | 1 | |
| 22-953 | VALVE - pressure regulator (F-4 & F-5) | 1 | ||
| 55-5197 | BUSHING (7/8 x 5/8) | 1 | ||
| 23 | 98-5466 | ACCUMULATOR (F-4 & F-5) | 1 | |
| 98-5467 | ACCUMULATOR (F-2 & F-3) | 1 |
