Установкa Thermo King ATHENIA S805 Iveco схема HOSES & FITTING (KIT 701955, 701956) – 237E6
Обновление от: 12/15/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-4763 | TUBE - assy (discharge line) | 1 | |
| 33-2848 | O-RING (9/16 id) | 1 | ||
| 2 | 61-4765 | TUBE - assy (discharge line) | 1 | |
| 3 | 61-4764 | TUBE - assy (suction line) | 1 | |
| 4 | 61-4767 | TUBE - assy (suction line) | 1 | |
| 5 | 61-4771 | FITTING (#16) | 2 | |
| 6 | 61-3588 | FITTING (#20) | 2 | |
| 7 | 61-4770 | HOSE (#20) | A/R | |
| 8 | 61-4769 | HOSE (#16) | A/R | |
| 9 | 33-3191 | GASKET - flat | 8 | |
| 10 | 203-391 | TAPE - sealer | A/R | |
| 11 | 66-1273 | VALVE - hose check | 2 | |
| 12 | 41-6592 | VALVE - water (only for KIT 701955) | 1 |
