Установкa Thermo King ATHENIA S805 Iveco схема EVAPORATOR BASE 1 – 237C8
Обновление от: 4/7/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8301 | BASE - weldment | 1 | |
| 55-6994 | SCREW - base | 4 | ||
| 55-7170 | LOCKWASHER | 4 | ||
| 55-7075 | FLATWASHER | 4 | ||
| 55-7373 | NUT - captive, evaporator base to air intake (M6) | 4 | ||
| 55-8403 | NUT - captive, evaporator base to bus roof (M8) | 6 | ||
| 2 | 55-9194 | NUT - captive | 3 | |
| 3 | 92-7774 | PLATE - covering | 1 | |
| 4 | 92-7775 | PLATE - covering (only for unit w/heater) | 1 | |
| 92-7776 | PLATE - covering (only for unit w/o heater) | 1 | ||
| 55-5130 | RIVET - plates | A/R | ||
| 5 | 92-5666 | PLATE - covering | 1 | |
| 6 | 92-6376 | ROD - COVER | 1 | |
| 7 | 92-5048 | BRACKET - rod | 1 | |
| 55-5130 | RIVET - bracket | A/R | ||
| 8 | 51-1669 | CLIP - plastic | 1 | |
| 9 | 83-258 | GROMMET (0.250 id) | 1 | |
| 10 | 51-809 | LOCKWASHER | 1 | |
| 11 | 92-4027 | NAMEPLATE - fuse | 1 | |
| 12 | 91-7510 | NAMEPLATE - gas in | 1 | |
| 13 | 91-8536 | NAMEPLATE - vapor out | 1 | |
| 14 | 33-428 | GROMMET (0.500 id) | 1 | |
| 15 | 33-1084 | GROMMET (1.000 id) | 1 | |
| 16 | 33-451 | GROMMET (0.375 id) | 1 | |
| 17 | 33-452 | GROMMET (0.875 id) | A/R | |
| 18 | 51-1631 | STRAP - cable | 7 | |
| 19 | 99-3281 | MOUNT - bandwrap | A/R | |
| 55-5130 | RIVET - mount | A/R | ||
| 20 | 56-546 | CLAMP | 1 | |
| 55-7169 | SCREW - clamp | 1 | ||
| 55-7171 | LOCKWASHER | 1 | ||
| 55-7089 | FLATWASHER | 1 | ||
| 55-8375 | NUT - captive | 1 | ||
| 21 | 92-5663 | FILTER - evaporator | 1 | |
| 22 | 92-5664 | CLIP - filter | 3 | |
| 23 | 92-7792 | FILTER - evaporator | 2 | |
| 24 | 92-6377 | INSULATION | 1 | |
| 25 | 92-7779 | INSULATION | 1 | |
| 26 | 92-7780 | INSULATION | 1 | |
| 27 | 92-7781 | INSULATION | 1 | |
| 28 | 33-3540 | STRIP - neoprene | A/R | |
| 29 | 99-2495 | STRIP - neoprene | A/R | |
| 30 | 99-6968 | STRIP - neoprene (50 ft cut to length) | A/R | |
| 31 | 33-2420 | STRIP - neoprene | A/R |
