Установкa Thermo King ATHENIA S805 Iveco схема 4 CYLINDER COMPRESSOR (FKX40/560K & FKX40/655K) – 184H5
Обновление от: 6/26/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 102-846 | COMPRESSOR - assembly (FKX 40/560K) | 1 | ||
| 102-805 | COMPRESSOR - assembly (FKX 40/655K) | 1 | ||
| 1 | 22-1236 | CRANKSHAFT - set | 1 | |
| 2 | 55-9268 | KEY - crankshaft | 1 | |
| 3 | 77-2719 | BEARING - crankshaft | 2 | |
| 4 | 33-3121 | GASKET - flange | 1 | |
| 5 | 33-4187 | O-RING | 1 | |
| 6 | 77-2540 | FLANGE - front bearing | 1 | |
| 7 | 55-9267 | SCREW - flange | 14 | |
| 8 | 22-1333 | PLUG - hose | 1 | |
| 9 | 20-170 | SEAL - shaft | 1 | |
| 10 | 33-3122 | GASKET - seal | 1 | |
| 11 | 55-9269 | WASHER - crankshaft | 1 | |
| 12 | 55-9270 | LOCKWASHER | 1 | |
| 13 | 55-9271 | SCREW - crankshaft | 1 | |
| 14 | 22-1271 | PISTON - set | 4 | |
| 15 | 33-3116 | CIRCLIP | 8 | |
| 16 | 22-1168 | PIN - piston | 4 | |
| 17 | 22-1272 | RING - piston | 4 | |
| 18 | 22-1273 | RING - piston | 4 | |
| 19 | 22-1071 | ROD - connecting | 4 | |
| 20 | 22-1072 | PUMP - oil | 1 | |
| 21 | 33-3118 | GASKET - flange | 1 | |
| 22 | 33-4188 | RING - bearing | 1 | |
| 23 | 55-9259 | SCREW - base & flange | 26 | |
| 24 | 55-9266 | PLUG | 2 | |
| 25 | 33-3119 | GASKET - plug | 3 | |
| 26 | 22-1074 | FILTER - oil | 1 | |
| 27 | 22-1070 | SIGHT GLASS (dia 18, up to version code 012) | 2 | |
| 22-1336 | SIGHT GLASS (dia 22, as of version code 013) | 2 | ||
| 28 | 33-3120 | O-RING - sight glass (dia.23 , up to version code 12) | 2 | |
| 22-1334 | O-RING - sight glass (dia.28 , as of version code 13) | 2 | ||
| 29 | 33-3111 | GASKET - plate | 1 | |
| 30 | 22-1059 | PLATE - base | 1 | |
| 31 | 22-1239 | VALVE | 1 | |
| 32 | 22-1060 | VALVE - safety | 1 | |
| 33 | 51-1241 | PLUG | 2 | |
| 34 | 22-1340 | SCREW - plate | 2 | |
| 35 | 22-1341 | PLATE - cover | 1 | |
| 36 | 22-1342 | GASKET - valve | 5 | |
| 37 | 41-3104 | COIL - solenoid (24VDC) | 1 | |
| 38 | 41-3106 | VALVE - regulator | 1 | |
| 39 | 55-9275 | NUT & O-RING | 1 | |
| 40 | 55-9274 | DISC | 1 | |
| 41 | 33-3125 | O-RING - valve | 1 | |
| 42 | 22-1067 | HEAD - cylinder (w/unloader) | 1 | |
| 43 | 55-9273 | SCREW - cylinder head | 11 | |
| 44 | 55-9272 | SCREW - cylinder head | 11 | |
| 45 | 22-1066 | HEAD - cylinder | 2 | |
| 46 | 33-3124 | GASKET - head | 2 | |
| 47 | 22-1065 | PLATE - valve | 2 | |
| 48 | 33-4351 | GASKET - valve plate | 2 | |
| 49 | 55-9260 | SCREW - valve | 2 | |
| 50 | 22-1082 | VALVE - shut off | 2 | |
| 51 | 55-9262 | NUT - bonnet | 2 | |
| 52 | 55-9263 | PLUG | 3 | |
| 53 | 55-9261 | CAP - valve | 2 | |
| 54 | 33-3113 | FILTER - suction | 1 | |
| 55 | 51-1242 | SCREW - valve | 2 | |
| 56 | 22-1241 | FLANGE | 1 | |
| 57 | 33-3311 | GASKET - valve | 8 | |
| 58 | 22-1343 | FLATWASHER | 26 | |
| 59 | 22-1344 | HOLDER - hose | 1 | |
| 60 | 22-1345 | CLAMP - hose | 1 |
