Установкa Thermo King AT10-M12 схема COMPRESSOR GROUP (2C45049G06, KIT 720060) – 182C6
Обновление от: 6/13/03
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-503 | COMPRESSOR - X640 (R22, see 177H6) | 1 | |
| 2 | 41-4558 | SWITCH - lpco (for connectors see 115D14) | 1 | |
| 41-4559 | SWITCH (only) | 1 | ||
| 33-768 | GASKET - switch | 1 | ||
| 3 | 41-4486 | SWITCH - hpco (for connectors see 115D14) | 1 | |
| 41-4809 | SWITCH (only) | 1 | ||
| 4 | 33-2805 | GASKET - valve | 1 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 5 | 33-2805 | GASKET - manifold | 3 | |
|
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 6 | 11-5513 | ELBOW - suction valve | 1 | |
| 11-7777 | CORE - valve | 1 | ||
| 55-1983 | CAP - flare | 1 | ||
| 7 | 55-129 | SCREW - valve | 2 | |
| 8 | 55-896 | FLATWASHER (3/8) | 2 | |
| 9 | 61-2134 | VALVE & TUBE (see 185A4) | 1 | |
| 10 | 33-230 | O-RING - valve (1.875 id) | 1 | |
|
10-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 380 ₽ |
|
| PP-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 220 ₽ |
|
|
| 11 | 33-2120 | SEAL - oil | 1 | |
|
10-33-2120 | Сальник крышки компрессора X426/430/640 | 1 690 ₽ |
|
| PP-33-2120 | Сальник крышки компрессора X426/430/640 | 480 ₽ |
|
|
| 12 | 55-5887 | ADAPTER - discharge (#20) | 1 | |
| 13 | 33-1777 | O-RING | 1 | |
| 14 | 55-308 | ELBOW - discharge valve | 1 | |
| 55-1983 | CAP - elbow | 1 | ||
| 15 | 55-6804 | WASHER - sealing | 2 | |
| 16 | 55-3674 | SCREW - discharge valve | 2 | |
| 17 | 61-2136 | VALVE - discharge (see 185A5) | 1 | |
| 18 | 66-2296 | CAP - service valve (plastic, incl gasket) | 1 | |
| P-17-10812-01 | Крышка сервисного клапана, пластик, 05K/05G/06D | 1 800 ₽ |
|
|
|
10-66-2296 | Крышка сервисного клапана, пластик, X426/430/640 | 1 800 ₽ |
|
| 66-3015 | CAP - valve (brass, incl gasket) | 1 | ||
|
10-66-3015 | Крышка сервисного клапана, латунь, X426/430/640 | 3 000 ₽ |
|
| P-17-10806-10 | Крышка сервисного клапана, латунь, 05K/05G/06D | 3 000 ₽ |
|
|
| 19 | 33-3007 | GASKET - plastic cap | 1 | |
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 33-350 | GASKET - brass cap | 1 | ||
| 20 | 55-6822 | SCREW - manifold | 4 | |
| 21 | 55-6804 | WASHER - sealing | 6 | |
| 22 | 55-6806 | SCREW | 2 | |
| 10-55-6806 | Болт головки компрессора 3/8-16 x 5/8 lg | 580 ₽ |
|
|
| 23 | 41-4810 | HARNESS - compressor (for connectors see 115D14) | 1 | |
| 24 | 41-3345 | SENSOR - high temperature (for connectors see 115D14) | 1 | |
| 25 | NSS | CLUTCH - assembly | 1 | |
| 107-192 | KIT - clutch drive repair (see 153E8) | 1 | ||
| 26 | 77-1083 | PLATE | 1 | |
| 27 | 45-1965 | FIELD - clutch (24VDC) | 1 | |
| 28 | 77-1672 | PULLEY (2-5V grooves, 7.75 in od) | 1 | |
| 29 | 22-710 | MANIFOLD - discharge | 1 | |
| 30 | 92-2700 | BRACKET - harness | 1 | |
| 31 | 55-9227 | CLAMP (0.375 dia) | 1 | |
| 55-3027 | SCREW - clamp | 1 | ||
| 55-2964 | LOCKWASHER | 1 | ||
| 55-2001 | FLATWASHER | 1 | ||
| 55-8798 | INSERT | 1 |
