Установкa Thermo King AP-II X 1012 схема FAN, BELT & PULLEYS – 156E3
Обновление от: 12/10/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 77-2500 | PULLEY - engine | 1 | |
| 2 | 55-5589 | SCREW - pulley | 4 | |
| 3 | 55-5411 | LOCKWASHER | 4 | |
| 4 | 70-212 | PULLEY - crankshaft (see 142C14) | 1 | |
| 5 | 78-1124 | BELT - alternator (set of 2) | 1 | |
| 6 | 77-1240 | PULLEY - alternator (3.25 od) | 1 | |
| 55-5321 | NUT - pulley | 1 | ||
| 55-5058 | FLATWASHER | 1 | ||
| 203-460 | SEALER - antiseize | A/R | ||
| 7 | 78-667 | BELT - water pump & alternator | 1 | |
| 10-78-667 | Ремень, SB-II, SB-II MAX, Isuzu 2.2 D.I., 2.2 S.E. | 2 640 ₽ |
|
|
| 8 | 77-2066 | PULLEY - alternator | 1 | |
| 9 | 77-1426 | PULLEY - fan (see 142F7) | 1 | |
|
10-77-1426 | Шкив водяной помпы, Yanmar 374 / 388 / 395 / 482 / 486, SL/SLe | 6 670 ₽ |
|
| 10 | 77-2499 | SPACER - fan | 1 | |
| 11 | 78-416 | FAN | 1 | |
| 12 | 55-141 | SCREW - fan | 3 | |
| 55-790 | LOCKWASHER | 3 | ||
| 13 | 204-427 | GAUGE - belt tension | 1 |
