Установкa Thermo King схема COMPRESSOR GROUP (KIT 710578) – 61D13
Обновление от: 12/16/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-913 | COMPRESSOR - X426 C5 (subassembly, see 231A2) | 1 | |
| 8102-913 | COMPRESSOR - X426 C5 (subassembly, reman, see 231A2) | 1 | ||
| 2 | 22-749 | MANIFOLD - discharge | 2 | |
| 3 | 33-2805 | GASKET | 3 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 4 | 55-6822 | SCREW - manifold | 4 | |
| 55-6804 | WASHER - sealing | 4 | ||
| 5 | 55-5261 | CLAMP - harness | 3 | |
| 6 | 66-2296 | CAP - service valve (plastic, incl gasket) | 1 | |
| P-17-10812-01 | Крышка сервисного клапана, пластик, 05K/05G/06D | 1 800 ₽ |
|
|
|
10-66-2296 | Крышка сервисного клапана, пластик, X426/430/640 | 1 800 ₽ |
|
| 33-3007 | GASKET | 1 | ||
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 7 | Not Used | |||
| 8 | Not Used | |||
| 9 | 55-466 | ELBOW | 1 | |
| 10 | 55-1983 | CAP | 1 | |
| 33-768 | GASKET - cap | 1 | ||
| 11 | Not Used | |||
| 12 | 44-3842 | DIODE - assembly | 1 | |
| 44-3940 | DIODE - only | 1 | ||
| 55-2996 | LOCKWASHER (internal tooth) | 1 | ||
| 13 | 55-3158 | PLUG - pipe | 1 | |
| 14 | 66-4124 | VALVE - suction | 1 | |
| 66-4125 | TUBE - suction | 1 | ||
| 66-3576 | VALVE - only (incl 6) | 1 | ||
| 55-4185 | ADAPTER - suction tube | 2 | ||
| 15 | 55-201 | SCREW - valve | 2 | |
| 55-896 | FLATWASHER | 2 | ||
| 16 | 33-2541 | GASKET - suction valve | 1 | |
| 17 | 66-1896 | ADAPTER - suction valve | 1 | |
| 18 | 99-7798 | BRACKET - suction tube | 1 | |
| 19 | 55-5122 | U-BOLT | 1 | |
| 55-4953 | NUT | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 20 | 33-544 | O-RING | 1 | |
| 21 | 22-754 | PLATE - drive bearing | 1 | |
| 33-2513 | GASKET - plate | 1 | ||
|
10-33-2513 | Прокладка передней крышки, X418/426/430/640 | 1 450 ₽ |
|
| PP-33-2513 | Прокладка передней крышки, X418/426/430/640 | 500 ₽ |
|
|
| 22 | 55-2381 | SCREW - plate | 9 | |
| 55-896 | FLATWASHER | 9 | ||
| 23 | 22-778 | SEAL - crankshaft | 1 | |
| 22-778 OEM | Сальник коленвала, X418/X426/X430 | 14 860 ₽ |
|
|
|
10-22-778 | Сальник коленвала, X418/X426/X430 | 11 920 ₽ |
|
|
PP-22-778 | Сальник коленвала, X418/X426/X430 | 2 720 ₽ |
|
| 24 | Not Used | |||
| 25 | 99-6980 | BRACKET - alternator support | 1 | |
| 55-2683 | SCREW - bracket | 3 | ||
| 55-2641 | FLATWASHER | 3 | ||
| 55-2363 | LOCKWASHER | 3 | ||
| 55-2640 | NUT | 3 | ||
| 26 | 99-6981 | BRACKET - alternator adjusting | 1 | |
| 27 | 99-7799 | BRACKET - compressor support (left) | 1 | |
| 28 | 55-2683 | SCREW - bracket | 6 | |
| 55-1243 | WASHER | 6 | ||
| 55-4955 | NUT | 6 | ||
| 29 | 78-585 | BELT - alternator (45 in) | 1 | |
| 10-78-585 | Ремень, MD-II, KD-II (30 & 50) (3/88-12/88) | 4 360 ₽ |
|
|
| 30 | 77-1512 | PULLEY - pto | 1 | |
| 31 | 77-1629 | BUSHING - pulley | 1 | |
| 55-5188 | SCREW - bushing | 2 | ||
| 32 | 78-590 | BELT - compressor (EL55) | 1 | |
| 33 | See Note | CLUTCH (12VDC) | 1 | |
| 107-150 | KIT - clutch drive repair (see 119G6) | 1 | ||
| 77-1414 | PULLEY (3-3V grooves, 8.0 in od) | 1 | ||
| 45-407 | FIELD - coil (12VDC) | 1 | ||
| 34 | 55-3631 | SCREW - clutch | 1 | |
| 77-2498 | SPACER | 1 | ||
|
10-77-2498 | Шайба муфты сцепления | 990 ₽ |
|
| 35 | 55-9024 | KEY - clutch (1-1/2 in lg) | 1 | |
|
10-55-9024 | Шпонка коленвала, X418/426/430 | 590 ₽ |
|
| 36 | 55-3451 | STUD - clutch | 3 | |
| 55-789 | NUT - clutch | 3 | ||
| 55-790 | LOCKWASHER | 3 | ||
| 37 | 98-2675 | PLATE - compressor base | 1 | |
| 38 | 55-2604 | SCREW - compressor (2-1/4 in lg) | 2 | |
| 55-3748 | SCREW - compressor (2-1/2 in lg) | 2 | ||
| 39 | 55-5186 | WASHER - special | 4 | |
| 40 | 55-399 | WASHER - special | 4 | |
| 41 | 55-2200 | LOCKWASHER | 4 | |
| 42 | 55-3122 | NUT | 4 | |
| 43 | 92-6932 | BOLT - eye (adjustment) | 2 | |
| 44 | 55-2173 | FLATWASHER | 4 | |
| 55-4952 | NUT | 4 | ||
| 45 | 99-7800 | BRACKET - compressor support (right) | 1 | |
| 46 | 55-3641 | SCREW - bracket to transmission | 4 | |
| 47 | Not Used | |||
| 48 | 99-6983 | SPACER - compressor | 4 | |
| 49 | 55-2280 | SPACER | 4 | |
| 50 | 55-3747 | SCREW | 2 |
