Установкa Thermo King схема CONTROL BOX (MD-I 30 SSIV) – 60A3
Обновление от: 6/30/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-6310 | SOCKET - light | 4 | |
| 44-5654 | TERMINAL - bulb | 4 | ||
| 2 | 61-3467 | THERMOMETER (dual scale) | 1 | |
|
10-61-3467 | Термометр | 15 250 ₽ |
|
| 66-1153 | LENS - thermometer | 1 | ||
| 33-666 | GASKET - thermometer glass | 1 | ||
| 33-2430 | GASKET - lens (use on plastic body thermometer) | 1 | ||
| 41-2590 | THERMOMETER - digital LED (F) | 1 | ||
| 44-5234 | SENSOR (10 ft) | 1 | ||
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 55-3256 | SCREW - thermometer | 3 | ||
| 55-1266 | FLATWASHER | 3 | ||
| 55-5754 | NUT | 3 | ||
| 3 | 44-2260 | GAUGE - oil pressure | 1 | |
|
10-44-2260 | Датчик давления масла | 6 600 ₽ |
|
| 55-3050 | ELBOW | 1 | ||
| 66-3406 | HOSE - oil pressure gauge | 1 | ||
| 4 | 44-2814 | GAUGE - water temperature | 1 | |
|
10-44-2814 | Датчик температуры воды | 15 730 ₽ |
|
| 5 | 40-512 | KIT - thermostat (replaces U.E. thermostat) | 1 | |
| 45-1564 | THERMOSTAT - TG | 1 | ||
| 6 | 99-7972 | COVER - thermostat | 1 | |
| 99-7973 | BASE - cover | 1 | ||
| 55-2828 | SCREW - thermostat | 4 | ||
| 7 | 44-9259 | HOURMETER - engine (analog) | 1 | |
|
10-44-9259 | Счетчик часов | 6 400 ₽ |
|
| 41-3450 | HOURMETER (digital) | 1 | ||
| 8 | 98-2528 | FRAME - condenser (see 59G13) | 1 | |
| 9 | 44-3035 | BULB - light | 4 | |
| 10 | 99-6903 | BAFFLE - light | 2 | |
| 11 | 99-6902 | BRACKET - indicator lights | 2 | |
| 55-3029 | SCREW | 4 | ||
| 55-2201 | FLATWASHER | 8 | ||
| 55-4223 | NUT | 4 | ||
| 12 | 99-6904 | NAMEPLATE - gauge panel | 1 | |
| 13 | 45-252 | PANEL - switch (see 67D6) | 1 | |
| 14 | 99-6912 | COVER - high voltage | 1 | |
| 99-4976 | STRIP - gasket | A/R | ||
| 55-2991 | SCREW - panel | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-2964 | LOCKWASHER | 2 | ||
| 55-4508 | NUT - captive | 2 | ||
| 15 | 44-7002 | HARNESS - main | 1 | |
| 44-5214 | SOCKET | 1 | ||
| 44-5220 | COVER | 1 | ||
| 55-103 | SCREW | 2 | ||
| 44-5219 | CONNECTOR | 2 | ||
| 44-5537 | SOCKET - relay | 1 | ||
| 44-5622 | CONNECTOR | 1 | ||
| 44-5030 | CONNECTOR (6-pin) | 1 | ||
| 44-5827 | CONNECTOR | 1 | ||
| 44-4925 | CONNECTOR | 1 | ||
| 16 | 44-9109 | RELAY (1pst) | 1 | |
| 17 | 44-5217 | HARNESS - indicator light | 1 | |
| 44-5030 | CONNECTOR (6-pin) | 1 | ||
| 41-6310 | SOCKET - light | 3 | ||
| 44-5654 | TERMINAL - bulb | 3 | ||
| 44-5814 | CONNECTOR (4-pin, female) | 1 | ||
| 18 | 44-7587 | HARNESS - thermostat | 1 | |
| 44-5537 | SOCKET - relay | 1 | ||
| 44-5220 | COVER - socket | 1 | ||
| 55-6036 | SCREW - cover | 2 | ||
| 44-4925 | CONNECTOR - wire (Nos. 8H, 7D) | 1 | ||
| 44-5600 | CONNECTOR - wire (Nos. 8H, 7D) | 1 |
