Установкa Thermo King схема 242 GALLON ELECTRICAL COMPONENTS – 255E8
Обновление от: 2/15/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 42-247 | SWITCH - power, main | 2 | |
| 2 | 42-246 | CONTROLLER - 4 button | 1 | |
| 3 | 610-205 | DISPLAY - remote {optional} | 1 | |
| 4 | 42-242 | RECTIFIER | 1 | |
| 5 | 41-226 | FUSE (40 amp) | 1 | |
|
10-41-226 | Предохранитель 40 ампер 10 шт | 1 860 ₽ |
|
| 6 | 42-243 | CORD - power, AC | 1 | |
| 7 | 42-265 | CORD - power, DC | 1 | |
| 8 | NSS | HOLDER - fuse | 1 | |
| 9 | 41-9454 | FUSE - 50 amp | 1 | |
| 10 | 40-1139 | KIT - relay (ignition, optional) | 1 | |
| 11 | 42-245 | RELAY (12V, freezing unit) | 1 | |
| 12 | 42-244 | CONTROLLER - compressor (freezing unit) | 1 | |
| 42-261 | CONTROLLER - compressor (cooling unit) | 1 | ||
| 13 | 102-1048 | COMPRESSOR (freezing unit) | 1 | |
| 102-1034 | COMPRESSOR (cooling unit) | 1 | ||
| 14 | 42-262 | FAN (freezing unit) | 1 | |
| 42-263 | FAN (cooling unit) | 2 | ||
| 15 | 44-9524 | FUSE - display (3 amp) | 1 | |
|
10-44-9524 | Предохранитель 3 ампер 10 шт | 1 860 ₽ |
|
| 16 | 41-1259 | FUSE (25 amp) | 1 | |
|
10-41-1259 | Предохранитель 25 ампер 10 шт | 1 860 ₽ |
|
