Установкa Thermo King схема CONTROL PANEL - IntelligAIRE III – 246H3
Обновление от: 7/30/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-8550 | PLATE - control | 1 | |
| 55-1587 | SCREW - plate | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 2 | 92-8551 | BRACKET - controller | 1 | |
| 55-2957 | SCREW - bracket | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-8711 | INSERT | 2 | ||
| 3 | 51-2034 | STANDOFF | 4 | |
| 4 | 41-9353 | MODULE - main, IntelligAIRE III | 1 | |
| 55-2997 | SCREW - module | 8 | ||
| 55-3014 | LOCKWASHER | 8 | ||
| 55-3013 | FLATWASHER | 8 | ||
| 5 | 92-8400 | MOUNT - cable tie | 4 | |
| 55-2330 | BANDWRAP (1.75 in) | A/R | ||
| 6 | 92-8552 | BRACKET - module | 1 | |
| 7 | 41-9354 | MODULE - I/O | 1 | |
| 55-2868 | SCREW - module | 4 | ||
| 55-3013 | FLATWASHER | 4 | ||
| 55-5754 | NUT - stop | 4 | ||
| 8 | 92-8553 | STRIP - mark | 1 | |
| 9 | 41-9521 | HARNESS - main, IntelligAIRE III (see 246G8) | 1 | |
| 10 | 44-9524 | FUSE (3 amp) | 1 | |
|
10-44-9524 | Предохранитель 3 ампер 10 шт | 1 860 ₽ |
|
| 11 | 41-1292 | FUSE (5 amp) | 2 | |
|
10-41-1292 | Предохранитель 5 ампер 10 шт | 1 860 ₽ |
|
| 12 | 44-9344 | FUSE (15 amp) | 1 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 13 | 41-896 | RELAY - boost pump | 1 | |
| 14 | 44-5537 | SOCKET - mini plug | 1 | |
| 15 | 91-6272 | CAP - dust | 1 | |
| 41-7774 | LANYARD - nylon | 1 | ||
| 55-3000 | SCREW - lanyard | 1 | ||
| 55-2996 | LOCKWASHER | 2 | ||
| 55-2001 | FLATWASHER | 5 | ||
| 55-2965 | NUT | 2 | ||
| 16 | 204-1927 | KIT - IntelligAIRE III CAN diagnostic | 1 |
