Установкa Thermo King схема REFRIGERATION CONDENSER (10 & 30, before 2/11) – 192E8
Обновление от: 8/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 66-8548 | SEPARATOR - oil | 1 | |
|
66-8548 OEM | Масляный сепаратор, V/VM-Series | 18 750 ₽ |
|
|
10-66-8548 | Масляный сепаратор, V/VM-Series | 4 870 ₽ |
|
| 2 | 55-6225 | CLAMP - filter | 2 | |
| 3 | 33-566 | O-RING - discharge (#8) | 3 | |
| 4 | 61-2503 | TUBE - discharge (before 12/05, w/ 2 service ports, item 5) | 1 | |
| 61-4759 | TUBE - discharge (12/05 & after, w/ one service port, item 5) | 1 | ||
| 5 | 61-2504 | VALVE - service port (Schrader) | 1 | |
| 6 | 61-469 | NUT - adapter (#8) | 2 | |
| 61-470 | SHOULDER (#8) | 2 | ||
| 7 | 61-434 | FITTING - defrost (#6) | 1 | |
| 8 | 33-1015 | O-RING - defrost (#6) | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 9 | 41-5781 | TRANSDUCER - discharge | 1 | |
| 41-5781 OEM | Трансдюсер, V-Series | 32 730 ₽ |
|
|
|
10-41-5781 | Трансдюсер, V-Series | 3 820 ₽ |
|
| 10 | 92-3463 | BRACKET - tube | 1 | |
| 55-9898 | RIVET - bracket | 2 | ||
| 11 | 92-1501 | CLAMP - tube | 1 | |
| 55-7340 | SCREW - clamp | 1 | ||
| 55-7404 | LOCKWASHER | 1 | ||
| 55-7089 | FLATWASHER | 1 | ||
| 12 | 67-2001 | COIL - condenser | 1 | |
| 55-9898 | RIVET - coil | 12 | ||
| 13 | 61-2655 | TUBE - liquid (before 2/09, use with dehydrator 66-8065) | 1 | |
| 61-4760 | TUBE - liquid (2/09 & after, use with dehydrator 61-3851) | 1 | ||
| 14 | 66-8065 | DEHYDRATOR - o-ring seal (before 2/09) | 1 | |
| 66-8065 OEM | Дегидратор, C/V-Series | 7 250 ₽ |
|
|
|
10-66-8065 | Дегидратор, C/V-Series | 3 350 ₽ |
|
| 61-3851 | DEHYDRATOR - o-ring seal (2/09 & after) | 1 | ||
| 15 | 66-8738 | SIGHT GLASS (#4) | 1 | |
| 16 | 61-2505 | TUBE - discharge (MAX 30 only) | 1 | |
| 17 | 66-9032 | VALVE - solenoid (MAX 30 only, see 193A5) | 1 | |
| 60-323 | KIT - repair (Danfoss) | 1 | ||
| 18 | 41-5789 | COIL (12V) | 1 | |
| 41-5791 | COIL (24V) | 1 | ||
|
10-41-5791 | Катушка соленоида 24V, V-Series | 4 760 ₽ |
|
| PP-41-5791 | Катушка соленоида 24V, V-Series | 1 830 ₽ |
|
|
| 19 | 33-1461 | O-RING - liquid (#4) | 3 | |
| 20 | 92-1714 | PANEL - deflector (V-200/300 & C-200/300 only) | 1 | |
| 21 | 61-4894 | TUBE - liquid line (V-100 10 MAX) | 1 | |
| 66-8669 | VALVE - check | 1 |
