Установкa Thermo King схема CONTROL BOX – 173H3
Обновление от: 4/28/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-7173 | BRACKET - control box | 1 | |
| 55-9620 | SCREW - bracket | 6 | ||
| 55-7404 | LOCKWASHER | 10 | ||
| 2 | 41-4456 | CHANNEL - din | 1 | |
| 55-9495 | RIVET - channel | 2 | ||
| 3 | 41-4259 | BOARD - printed circuit (N9.2) | 1 | |
| 55-9620 | SCREW - board | 3 | ||
| 55-7861 | LOCKWASHER | 3 | ||
| 55-7698 | NUT | 3 | ||
| 4 | 41-895 | RELAY (12V) | 6 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 5 | 41-2978 | FUSE (20 amp) | 1 | |
| 30-41-2978 | Предохранитель 32V 20А | 500 ₽ |
|
|
| 44-9344 | FUSE (15 amp) | 2 | ||
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 44-9524 | FUSE (3 amp) | 1 | ||
|
10-44-9524 | Предохранитель 3 ампер 10 шт | 1 860 ₽ |
|
| 6 | 41-3782 | CABLE - power (see 173H2) | 1 | |
| 7 | 41-898 | CONNECTOR - end | 2 | |
| 8 | 41-942 | CONNECTOR - fuse | 1 | |
| 9 | 41-3661 | FUSE (4 amp) | 1 | |
| 10 | 41-3097 | RELAY - overload (4 to 6.3 amps) | 1 | |
| 11 | 41-3099 | SOCKET - circuit breaker | 1 | |
| 12 | 42-271 | CONTACTOR (12V) | 1 |
