Установкa Thermo King схема COMPRESSOR GROUP (2C45049G01, KIT 719111) – 166H9
Обновление от: 7/16/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-758 | COMPRESSOR - X640 (see 100B4) | 1 | |
| 45-1227 | FIELD - clutch | 1 | ||
| 45-1965 | FIELD - clutch (w/ internal wiring) | 1 | ||
| 77-1672 | PULLEY (2-5V grooves, 7.75 in od) | 1 | ||
| 2 | 107-192 | KIT - clutch drive repair (see 153E8) | 1 | |
| 3 | 22-1146 | SPACER - suction valve | 1 | |
| 4 | 33-230 | O-RING - adapter (1.875 id) | 2 | |
|
10-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 380 ₽ |
|
| PP-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 220 ₽ |
|
|
| 5 | 41-4147 | SWITCH - lpco | 1 | |
| 41-4530 | SWITCH | 1 | ||
| 6 | 55-7213 | ADAPTER | 1 | |
| 33-768 | GASKET - flare | 1 | ||
| 7 | 66-7180 | FITTING - suction | 1 | |
| 66-7183 | CAP - fitting (blue) | 1 | ||
| 8 | 55-529 | SCREW - valve | 2 | |
| 9 | 55-896 | FLATWASHER (3/8) | 2 | |
| 10 | 66-5318 | VALVE - suction | 1 | |
| 66-5318 OEM | Всасывающий клапан X426/430/640 | 42 100 ₽ |
|
|
|
10-66-5318 | Всасывающий клапан X426/430/640 | 28 770 ₽ |
|
| 66-2296 | CAP - service valve (plastic, incl gasket) | 1 | ||
| P-17-10812-01 | Крышка сервисного клапана, пластик, 05K/05G/06D | 1 800 ₽ |
|
|
|
10-66-2296 | Крышка сервисного клапана, пластик, X426/430/640 | 1 800 ₽ |
|
| 33-3007 | GASKET - cap | 1 | ||
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 11 | 33-920 | O-RING - adapter | 1 | |
| 12 | 55-6570 | ADAPTER - suction | 1 | |
| 13 | 33-1777 | O-RING - discharge | 1 | |
| 14 | 55-7537 | ADAPTER - discharge (#20) | 1 | |
| 15 | 55-308 | ELBOW - discharge valve | 1 | |
| 16 | 55-6804 | WASHER - sealing | 2 | |
| 17 | 55-3674 | SCREW - discharge valve | 2 | |
| 18 | 66-2140 | VALVE - discharge | 1 | |
| 66-2296 | CAP - service valve (plastic, incl gasket) | 1 | ||
|
|
10-66-2296 | Крышка сервисного клапана, пластик, X426/430/640 | 1 800 ₽ |
|
| P-17-10812-01 | Крышка сервисного клапана, пластик, 05K/05G/06D | 1 800 ₽ |
|
|
| 33-3007 | GASKET - plastic cap | 1 | ||
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 66-3015 | CAP - valve (brass, incl gasket) | 1 | ||
|
10-66-3015 | Крышка сервисного клапана, латунь, X426/430/640 | 3 000 ₽ |
|
| P-17-10806-10 | Крышка сервисного клапана, латунь, 05K/05G/06D | 3 000 ₽ |
|
|
| 33-2805 | GASKET - brass cap | 1 | ||
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 20 | 66-8086 | FITTING - discharge | 1 | |
| 21 | 66-7182 | CAP - fitting (red) | 1 | |
| 22 | 61-930 | TUBE - discharge | 1 | |
| 23 | 55-9731 | SCREW - adapter | 2 | |
| 24 | 61-931 | TUBE - suction | 1 | |
| 25 | 41-3345 | SENSOR - probe | 1 | |
| 26 | 41-4130 | HARNESS - compressor | 1 | |
| 27 | 44-8294 | CONNECTOR - shroud (6-pin) | 1 | |
| 28 | 41-1789 | CONNECTOR - tower (6-pin) | 1 | |
| 41-1790 | LOCK - secondary (6-pin connector) | 1 | ||
| 29 | 41-4280 | DIODE | 1 | |
| 30 | 41-1787 | COVER - connector | 1 | |
| 31 | 41-4146 | SWITCH - hpco | 1 | |
| 41-4531 | SWITCH - only | 1 |
