Установкa Thermo King схема EVAPORATOR REFRIGERATION (ECT-I 50, 714465) – 147E3
Обновление от: 3/6/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-1522 | COIL - evaporator | 1 | |
| 55-1587 | SCREW - coil to housing | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-2086 | FLATWASHER | 8 | ||
| 55-3059 | NUT - captive | 8 | ||
| 2 | 66-6119 | TUBE - equalizer | 1 | |
| 3 | 66-8200 | VALVE - expansion | 1 | |
| 66-6047 | SCREEN - inlet | 1 | ||
| 66-5336 | ELEMENT - power | 1 | ||
| 55-2977 | SCREW - valve | 1 | ||
| 55-3121 | SCREW - clamp | 1 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-3059 | NUT - captive | 2 | ||
| 4 | 66-6120 | TUBE - solenoid to expansion | 1 | |
| 5 | 66-6384 | VALVE - solenoid (liquid/defrost, see 116G10) | 1 | |
|
10-66-6384 | Соленоид, MD/RD-II / SB-III/ SMX/SMX-II/V-Series | 13 550 ₽ |
|
| 55-3029 | SCREW - valve | 2 | ||
| 55-2202 | LOCKWASHER | 2 | ||
| 55-2201 | FLATWASHER | 2 | ||
| 6 | 55-7142 | TEE | 1 | |
| 7 | 66-6222 | TUBE - tee | 1 | |
| 8 | 66-6223 | TUBE - liquid | 1 | |
| 9 | 66-622 | TEE | 1 | |
| 10 | 66-6224 | TUBE - plate to tee | 1 | |
| 11 | 55-3214 | ELBOW - tee to check valve | 1 | |
| 12 | 66-5721 | VALVE - check | 1 | |
| 66-5721 OEM | Обратный клапан | 19 660 ₽ |
|
|
| 55-1464 | ELBOW | 1 | ||
| 13 | 66-6267 | TUBE - check valve to tee | 1 | |
| 14 | 66-6125 | TUBE | 1 | |
| 15 | 91-758 | CLAMP - tube (5/8) | 1 | |
| 16 | 55-4322 | TEE | 1 | |
| 17 | 66-9209 | TUBE - tee to tee | 1 | |
| 66-5752 | FITTING | 1 | ||
| 18 | 55-7500 | COUPLING | 1 | |
| 19 | 66-6126 | TUBE - solenoid to plate | 1 | |
| 20 | 55-6389 | CLAMP - tube (1/2) | 3 | |
| 55-2979 | SCREW - clamp | 3 | ||
| 55-1800 | LOCKWASHER | 3 | ||
| 55-2086 | FLATWASHER | 3 | ||
| 55-3059 | NUT - captive | 3 | ||
| 21 | 66-6401 | VALVE | 2 | |
| 22 | 55-8432 | COUPLING | 1 | |
| 23 | 91-3332 | BRACKET - valve | 1 | |
| 24 | 91-3336 | BRACKET - tube (curbside, w/ 4 inserts) | 1 | |
| 25 | 91-3337 | BRACKET - tube (curbside, w/ 2 inserts) | 1 | |
| 26 | 91-3335 | BRACKET - tube (roadside, w/ 2 inserts) | 1 | |
| 27 | 91-3338 | BRACKET - tube (roadside, w/ 4 inserts) | 1 | |
| 55-2991 | SCREW - bracket | 4 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 55-4560 | NUT | 4 | ||
| 28 | 55-7143 | CLAMP - expansion valve | 1 | |
| 29 | 55-6174 | TEE | 1 | |
| 30 | 91-8853 | BRACKET - solenoid | 1 | |
| 55-2957 | SCREW - bracket | 3 | ||
| 55-4953 | NUT | 3 | ||
| 31 | 66-6269 | TUBE - liquid (curbside) | 1 |
