Установкa Thermo King XRT700 1004 24Vdc BRUSHLESS схема RETURN AIR GRILLE KIT (702429) – 265A4
Обновление от: 2/6/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8699 | FRAME | 1 | |
| 2 | 98-9204 | PANEL - filter | 1 | |
| 55-5047 | RIVET - panel | 4 | ||
| 3 | 92-8875 | LOCK | 2 | |
| 4 | 92-8940 | FILTER | 1 | |
| 5 | 91-9343 | CLIP - filter | 1 | |
| 6 | 91-9638 | NAMEPLATE - Thermo King | 1 |
