Установкa Thermo King XRT700 1004 24Vdc BRUSHLESS схема REFRIGERATION COMPONENTS – 263H0
Обновление от: 2/6/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 51-1911 | FLANGE - complete | 1 | |
| 55-5427 | SCREW - flange | 2 | ||
| 2 | 61-4822 | ADAPTER | 1 | |
| 3 | 55-9186 | FLANGE | 1 | |
| 4 | 92-8932 | BRACKET - flange | 1 | |
| 55-6994 | SCREW - bracket | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 5 | 61-5494 | TUBE - suction | 1 | |
| 6 | 66-6996 | FITTING - saddle | 2 | |
| 7 | 55-3364 | PLUG | 1 | |
| 8 | 41-5220 | SWITCH - condenser pressure switch | 1 | |
| 9 | 61-2059 | VALVE | 1 | |
| 10 | 203-391 | SEALER - tape | 1 | |
| 11 | 61-5496 | TUBE | 1 | |
| 12 | 91-372 | CLAMP - tube | 1 | |
| 55-8993 | SCREW - clamp | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 13 | 61-5476 | TUBE - reduction | 1 | |
| 14 | 306-1802 | Y-TUBE | 1 | |
| 15 | 61-5480 | TUBE | 1 | |
| 16 | 61-5481 | TUBE | 1 | |
| 17 | 55-8951 | SHOULDER | 2 | |
| 18 | 55-8950 | NUT - shoulder | 2 | |
| 19 | 33-566 | O-RING | 2 | |
| 20 | 67-2402 | COIL - condenser | 2 | |
| 55-7035 | SCREW - coil | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 8 | ||
| 55-7373 | NUT - captive | 8 | ||
| 21 | 33-1015 | O-RING | 2 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 22 | 55-6358 | NUT - shoulder | 2 | |
| 23 | 55-8268 | SHOULDER | 2 | |
| 24 | 61-5477 | TUBE | 2 | |
| 25 | 61-5478 | TUBE | 1 | |
| 26 | 61-5479 | TUBE | 1 | |
| 27 | 67-2608 | TANK - receiver | 1 | |
| 28 | 92-9412 | BRACKET - tank | 1 | |
| 29 | 55-2688 | CLAMP - tank | 1 | |
| 30 | 61-5498 | TUBE - tank | 1 | |
| 31 | 55-3295 | FITTING - saddle | 1 | |
| 32 | 66-7392 | VALVE - relief, complete | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 33 | 33-1015 | O-RING | 1 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 34 | 33-3669 | BUSHING - cable | 1 | |
| 35 | 66-1188 | INDICATOR - liquid (sight glass) | 1 | |
| 36 | 91-758 | CLAMP - tube | 1 | |
| 55-8316 | SCREW - clamp | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 37 | 61-5556 | TUBE | 1 | |
| 38 | 55-6837 | SHOULDER | 2 | |
| 39 | 55-6838 | NUT - shoulder | 2 | |
| 40 | 33-566 | O-RING | 2 | |
| 41 | 66-8344 | FILTER - dehydrator | 1 | |
| 42 | 92-8859 | HOLDER - dehydrator | 1 | |
| 55-7172 | SCREW - holder | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-8893 | FLATWASHER | 1 | ||
| 55-7373 | NUT - captive | 1 | ||
| 43 | 61-5500 | TUBE | 1 | |
| 44 | 33-3669 | BUSHING - cable | 1 | |
| 45 | 61-5502 | TUBE - connection | 1 | |
| 46 | 61-5484 | TUBE | 1 | |
| 47 | 55-6222 | TEE (3/8 x 3/8 x 1/2) | 1 | |
| 48 | 61-5510 | TUBE | 1 | |
| 49 | 61-5512 | TUBE | 1 | |
| 50 | 67-2604 | COIL - evaporator/heater | 1 | |
| 61-863 | VALVE - thermostatic expansion, R134a | 1 | ||
| 51 | 67-2603 | COIL - evaporator/heater | 1 | |
| 61-863 | VALVE - thermostatic expansion, R134a | 1 | ||
| 52 | 92-8798 | FILTER - evaporator | 2 | |
| 53 | 92-5664 | CLIP - filter | 4 | |
| 54 | 92-8802 | FILTER - evaporator | 2 | |
| 55 | 61-5514 | TUBE - equalizer | 1 | |
| 56 | 61-5516 | TUBE - equalizer | 1 | |
| 57 | 61-5558 | TUBE | 1 | |
| 58 | 61-5557 | TUBE | 1 | |
| 59 | 55-6508 | TEE (7/8 x 7/8 x 1-1/8) | 1 | |
| 60 | 61-5490 | TUBE | 1 | |
| 61 | 61-2059 | VALVE | 1 | |
| 62 | 55-5672 | CAP - valve | 1 | |
| 63 | 55-9186 | FLANGE | 1 | |
| 64 | 51-374 | ADAPTER (1 1/8")" | 1 | |
| 65 | 91-9143 | FLANGE - assembly | 1 | |
| 55-5427 | SCREW - flange | 2 | ||
| 66 | 51-2242 | CLAMP | 4 | |
| 67 | 92-8861 | PLATE | 1 | |
| 55-5130 | RIVET - plate | 3 | ||
| 68 | 91-5459 | NAMEPLATE - R134a | 1 |
