Установкa Thermo King XR-50 1004 Berkhof схема HEATING COMPONENTS – 198E2
Обновление от: 6/16/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-3538 | ADAPTER - heater (before 2/05) | 1 | |
| 61-3357 | ADAPTER - heater (2/05 & after) | 1 | ||
| 55-5130 | RIVET - adapter | A/R | ||
| 2 | 61-1100 | TUBE - adapter to valve (before 2/05) | 1 | |
| 3 | 41-4151 | VALVE - solenoid (water, before 2/05) | 1 | |
| 41-6592 | VALVE (2/05 & after) | 1 | ||
| 4 | 55-6788 | BOLT (before 2/05) | 2 | |
| 55-2001 | FLATWASHER (before 2/05) | 4 | ||
| 55-4560 | NUT (before 2/05) | 4 | ||
| 5 | 61-3007 | TUBE - valve to tee (before 2/05) | 1 | |
| 61-3358 | TUBE - hose to tee (2/05 & after) | 1 | ||
| 6 | 55-5401 | TEE (3/4 x 3/4 x 3/4) | 2 | |
| 7 | 61-2549 | TUBE - tee to evaporator | 1 | |
| 8 | 61-2548 | TUBE | 1 | |
| 9 | 67-1989 | COIL - evaporator (see 198E1) | 1 | |
| 10 | 61-2550 | TUBE - evaporator to tee | 1 | |
| 11 | 61-2551 | TUBE - evaporator to tee | 1 | |
| 12 | 92-5032 | HOSE - silicone (2/05 & after) | A/R | |
| 13 | 92-4465 | HOLDER - valve (before 2/05) | 1 | |
| 55-7340 | SCREW - holder (before 2/05) | 2 | ||
| 55-7171 | LOCKWASHER (before 2/05) | 2 | ||
| 55-7089 | FLATWASHER (before 2/05) | 2 | ||
| 55-8375 | NUT - captive (before 2/05) | 2 | ||
| 14 | 92-3539 | FILTER - air | 2 | |
| 15 | 92-3540 | CLIP - filter | 8 | |
| 16 | 91-7703 | NAMEPLATE - Liquid In | 1 | |
| 17 | 91-7550 | NAMEPLATE - Liquid Out | 1 | |
| 18 | 67-1990 | COIL - evaporator (see 198E1) | 1 | |
| 19 | 61-3033 | DISTRIBUTOR | 1 | |
| 92-4611 | HOLDER - distributor | 1 | ||
| 61-3034 | TUBE - distributor | 12 | ||
| 55-5130 | RIVET - holder | 2 | ||
| 20 | 55-3401 | CLAMP - hose (2/05 & after) | 4 |
