Установкa Thermo King XR-50 1000, 1004 схема HOSE & FITTINGS KIT – 202G1
Обновление от: 2/15/05
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-2848 | O-RING | 4 | |
| 2 | 55-9802 | FITTING - suction (#16, elbow, 45 deg) | 1 | |
| 3 | 61-1793 | HOSE (#16, 1 m length, Kit 719693) | 1 | |
| 61-1796 | HOSE (#16, 16 m length, Kit 719694) | 1 | ||
| 61-1797 | HOSE (#16, 9 m length, Kit 719695) | 1 | ||
| 61-1800 | HOSE (#16, 12 m length, Kit 719696) | 1 | ||
| 61-1801 | HOSE (#16, 14 m length, Kit 719697) | 1 | ||
| 61-1804 | HOSE (#16, 17 m length, Kit 719698) | 1 | ||
| 61-1805 | HOSE (#16, 13 m length, Kit 719800) | 1 | ||
| 61-1808 | HOSE (#16, 15 m length, Kit 719807) | 1 | ||
| 61-1809 | HOSE (#16, 16 m length, Kit 719808) | 1 | ||
| 4 | 55-9790 | FITTING - suction (#16, straight) | 1 | |
| 5 | 55-9793 | FITTING - suction (#16, elbow, 90 deg) | 2 | |
| 6 | 33-2847 | O-RING | 4 | |
| 7 | 61-1794 | HOSE (#10, 1 m length, Kit 719693) | 1 | |
| 61-1795 | HOSE (#10, 6 m length, Kit 719694) | 1 | ||
| 61-1798 | HOSE (#10, 9 m length, Kit 719695) | 1 | ||
| 61-1799 | HOSE (#10, 12 m length, Kit 719696) | 1 | ||
| 61-1802 | HOSE (#10, 14 m length, Kit 719697) | 1 | ||
| 61-1803 | HOSE (#10, 17 m length, Kit 719698) | 1 | ||
| 61-1806 | HOSE (#10, 13 m length, Kit 719800) | 1 | ||
| 61-1807 | HOSE (#10, 15 m length, Kit 719807) | 1 | ||
| 61-1810 | HOSE (#10, 16 m length, Kit 719808) | 1 | ||
| 8 | 55-9801 | FITTING - discharge (#10, straight) | 1 | |
| 9 | 55-9803 | FITTING - discharge (#10, elbow, 45 deg) | 1 | |
| 10 | 55-9798 | FITTING - discharge (#10, elbow, 90 deg) | 2 |
