Установкa Thermo King X900 схема KIT GRILLE CONDENSER (702310) – 252B1
Обновление от: 3/11/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8711 | GRILLE - condenser | 1 | |
| 2 | 92-8957 | HOLDER - grille | 3 | |
| 55-6994 | SCREW - grille | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 5 | ||
| 55-8893 | FLATWASHER | 3 | ||
| 55-6997 | NUT - captive | 3 |
