Установкa Thermo King X900 схема FILTERS & INSULATIONS – 237A6
Обновление от: 3/11/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-5663 | FILTER - evaporator | 2 | |
| 2 | 92-5664 | CLIP - filter | 6 | |
| 3 | 92-8953 | FILTER - evaporator (only for unit w/ heater 901128) | 2 | |
| 92-7801 | FILTER - evaporator (only for unit w/o heater 901127) | 2 | ||
| 4 | 92-7800 | FILTER - evaporator | 4 | |
| 5 | 98-8322 | INSULATION | 2 | |
| 6 | 92-7827 | INSULATION | 1 | |
| 8 | 92-7829 | INSULATION | 1 | |
| 9 | 92-7830 | INSULATION - (only for unit w/ heater 901128) | 1 | |
| 92-7831 | INSULATION - (only for unit w/o heater 901127) | 1 | ||
| 10 | 92-7832 | INSULATION | 1 | |
| 11 | 92-7833 | INSULATION | 1 | |
| 12 | 98-8323 | INSULATION | 1 | |
| 13 | 98-8324 | INSULATION | 1 | |
| 14 | 92-7834 | INSULATION | 1 | |
| 15 | 92-7835 | INSULATION | 1 | |
| 16 | 92-7836 | INSULATION - (only for unit w/ heater 901128) | 1 | |
| 92-7837 | INSULATION - (only for unit w/o heater 901127) | 1 | ||
| 17 | 98-8325 | INSULATION | 1 |
