Установкa Thermo King X900 схема FRAME – 237A5
Обновление от: 6/4/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8318 | BASE - weldment | 1 | |
| 2 | 98-8319 | HOLDER - cover | 1 | |
| 3 | 98-8320 | HOLDER - cover | 1 | |
| 55-6994 | SCREW - holder | 8 | ||
| 55-6996 | LOCKWASHER | 8 | ||
| 55-7075 | FLATWASHER | 8 | ||
| 55-7373 | NUT - captive | 10 | ||
| 4 | 55-9194 | NUT - captive, covers | 10 | |
| 5 | 98-8321 | HOLDER - control panel | 3 | |
| 55-5130 | RIVET - holder | A/R | ||
| 6 | 41-8969 | PLUG - (only for unit w/o heater) | 1 | |
| 55-5130 | RIVET - plug | A/R | ||
| 7 | 92-7825 | RIB - (optional) | 1 | |
| 8 | 92-7826 | RIB - (optional) | 1 | |
| 9 | 92-8951 | RIB - (optional) | 1 | |
| 10 | 92-9852 | RIB - (optional) | 1 | |
| 55-5130 | RIVET - rib | A/R | ||
| 11 | 99-3281 | MOUNT - cable tie | A/R | |
| 55-5130 | RIVET - mount | A/R | ||
| 55-7368 | FLATWASHER | A/R | ||
| 56-2330 | BAND - wrap | A/R | ||
| 12 | 51-1631 | STRAP - cable | 23 | |
| 13 | 33-1013 | GROMMET (0.281 id) | 1 | |
| 14 | 33-367 | GROMMET (0.625 id) | 1 | |
| 15 | 33-1084 | GROMMET (0.750 id) | 1 | |
| 16 | 33-452 | GROMMET (0.875 id) | 1 | |
| 17 | 92-3279 | RUBBER - profile | A/R | |
| 18 | 33-3540 | STRIP - neoprene | A/R | |
| 19 | 91-7543 | NAMEPLATE - 24V/DC | 1 | |
| 20 | 91-7550 | NAMEPLATE - liquid out (only for unit w/heater) | 1 | |
| 21 | 91-7703 | NAMEPLATE - liquid in (only for unit w/heater) | 1 | |
| 22 | 91-7510 | NAMEPLATE - gas in | 1 | |
| 23 | 91-8536 | NAMEPLATE - vapour out | 1 | |
| 24 | 91-5459 | NAMEPLATE - R134a | 1 |
