Установкa Thermo King X900 схема TK HIGH TORQUE CLUTCH (77-2840) – 222H3
Обновление от: 10/20/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 77-2840 | PULLEY - complete | 1 | |
| 2 | 77-2889 | PULLEY - clutch | 1 | |
| 3 | 77-2827 | BEARING - clutch | 1 | |
| 4 | 51-1107 | CIRCLIP | 1 | |
| 5 | 45-2106 | COIL (24VDC) | 1 | |
| 45-2204 | COIL (12VDC) | 1 | ||
| 6 | 77-2790 | HUB | 1 | |
| 7 | 77-2831 | SLEEVE - clamping | 1 | |
| 8 | 204-1147 | TOOL KIT | 1 | |
| 9 | 77-1491 | SPACER | 1 | |
| 10 | 204-1200 | WRENCH | 1 | |
| 11 | 204-477 | GUN - grease | 1 | |
| 204-476 | GREASE | A/R | ||
| 12 | 204-972 | TOOL - keyway alignment | 1 | |
| 13 | 204-481 | PULLER - clutch | 1 |
