Установкa Thermo King X900 BOX 1012 схема X900 BOX 1012 REFERENCE SHEET – 16U49
Обновление от: 7/30/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 901202 | System X900 1012 R134a Box Design | 01/12 | ||
| 008670 | Top Assembly - X900 1000 PLX | 01/12 | ||
| NOTE | For Power Pack TK486/V CANAIRE see TK 60861 | 01/12 | ||
| 008671 | Option - Electro X900 STD 24V CANAIRE | 01/12 | ||
| 008672 | Option - Fresh Air Damper X900 | 01/12 | ||
| 008673 | Option - No Fresh Air Damper X900 | 01/12 | ||
| 008675 | Option - Fresh Air Deflector X900 | 01/12 | ||
| 008696 | Kit - Insullation of Evaporator Bottom X900 | 01/12 | ||
| 008729 | Kit - Air Duct Distribution Plates X900 | 01/12 | ||
| 008730 | Kit - Add Air Duct Plates Distribution Box X900 | 05/13 | ||
| 008892 | Option - Fresh Air - Baffled X900 | 01/12 | ||
| 013002 | Option - Electric 24V CANAIRE CAN I X900 | 01/12 | ||
| 013543 | Option - Control Panel X900 on the left Side | 05/13 | ||
| 013763 | Option - Electric X900 24V PLAXTON CANAIRE | 05/13 | ||
| 013811 | Option - TKS for Power Pack | 05/13 | ||
| 013827 | Option - Electric 24V CANAIRE X900 PLAXTON | 05/13 | ||
| 013839 | Option - Evaporator Filters X900 | 05/13 | ||
| 700140 | Kit - Cover Power Pack - see TK 60861 | 01/12 | ||
| 700257 | Kit - T-Hose Fitting | 01/12 | ||
| 701823 | Kit - ClimaAIRE I D CAN 9m | 01/12 | ||
| 701824 | Kit - ClimaAIRE I D CAN 18m | 01/12 | ||
| 701825 | Kit - Harness Power | 01/12 | ||
| 701844 | Kit - Harness CAN 9m | 01/12 | ||
| 701894 | Kit - Return Air X900 Central | 01/12 | ||
| 701895 | Kit - Return Air X900 Side | 01/12 | ||
| 702187 | Kit - Harness CAN, 15m | 05/13 | ||
| 702353 | Kit - Grille Return Air Plastic X900 Central | 01/12 | ||
| 702354 | Kit - Grille Return Air Plastic X900 Side | 01/12 | ||
| 702619 | Kit - CAN Terminator | 01/12 | ||
| 702735 | Kit - Crate Dry X900 | 05/13 | ||
| 702860 | Kit - Multipack Crate X900 | 01/12 | ||
| 703330 | Kit - Multipack Crate 4 pcs X900 | 05/13 | ||
| 703331 | Kit - Multipack Crate 3 pcs X900 | 05/13 | ||
| 703340 | Kit - Power Pack CANAIRE TK486/V, R134a, Alternator, 12V - see TK 60861 | 01/12 | ||
| 703341 | Kit - Power Pack CANAIRE TK486/V, R134a, Idler, 12V - see TK 60861 | 01/12 | ||
| 703462 | Kit - CANAIRE Driver Panel w/ Harness, 5m | 05/13 | ||
| 703465 | Kit - CANAIRE Driver Panel w/ Harness, 9m | 05/13 | ||
| 703591 | Kit - CANAIRE Driver Panel w/ Harness, 14m | 05/13 | ||
| 720208 | Kit - Fitting Compressor X430 Side (Suct 0deg/Disch 0deg) | 01/12 | ||
| 720209 | Kit - Fitting Compressor X430 Side (Suct 45deg/Disch 45deg) | 01/12 | ||
| 720210 | Kit - Fitting Compressor X430 Side (Suct 90deg/Disch 90deg) | 01/12 | ||
| 720211 | Kit - Fitting Refrigeration Unit Side (Suct 0deg/Disch 0deg) | 01/12 | ||
| 720212 | Kit - Fitting Refrigeration Unit Side (Suct 90deg/Disch 90deg) | 01/12 | ||
| 720213 | Kit - Fitting Refrigeration Unit Side (Suct 45deg/Disch 45deg) | 01/12 | ||
| 720214 | Kit - Fitting Refrigeration Unit Side (Suct 90deg/Disch 0deg) | 01/12 | ||
| 720215 | Kit - Hose Refrigerant (#16, #20, 1m - w/o Fittings) | 01/12 | ||
| 720216 | Kit - Hose Refrigerant (#16, #20, 6m - w/o Fittings) | 01/12 | ||
| 720217 | Kit - Hose Refrigerant (#16, #20, 7m - w/o Fittings) | 01/12 | ||
| 720218 | Kit - Hose Refrigerant (#16, #20, 8m - w/o Fittings) | 01/12 | ||
| 720219 | Kit - Hose Refrigerant (#16, #20, 9m - w/o Fittings) | 01/12 | ||
| 720220 | Kit - Hose Refrigerant (#16, #20, 10m - w/o Fittings) | 01/12 | ||
| 720221 | Kit - Hose Refrigerant (#16, #20, 12m - w/o Fittings) | 01/12 | ||
| 720222 | Kit - Hose Refrigerant (#16, #20, 14m - w/o Fittings) | 01/12 | ||
| 720223 | Kit - Hose Refrigerant (#16, #20, 16m - w/o Fittings) | 01/12 | ||
| 720224 | Kit - Hose Refrigerant (#16, #20, 18m - w/o Fittings) | 01/12 | ||
| 720365 | Kit - Fitting Refrigerant Unit Side (Suct 0deg/Disch 90deg) | 01/12 | ||
| 720366 | Kit - Fitting Refrigerant Unit Side (Suct 90deg/Disch 45deg) | 01/12 | ||
| 720367 | Kit - Fitting Refrigerant Unit Side (Suct 45deg/Disch 90deg) | 01/12 | ||
| 720395 | Kit - Fitting - Tube Installation | 01/12 | ||
| 800355 | Kit - Drain Water Hose 20m | 01/12 | ||
| 800356 | Kit - Drain Water Hose 40m | 01/12 |
