Установкa Thermo King X500 AP схема HARNESS CONTROL PANEL TO COMPRESSOR – 262D0
Обновление от: 8/7/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 42-659 | HARNESS - control panel to compressor (12 m) | 1 | |
| 42-660 | HARNESS - control panel to compressor (14 m) | 1 | ||
| 2 | 41-8510 | CONNECTOR (9-pin) | 1 | |
| 41-8512 | TERMINAL - female (18 awg) | 7 | ||
| 41-8514 | SEAL - black | 7 | ||
| 3 | 44-5838 | CONNECTOR - tower (2-pin) | 1 | |
| 44-5839 | TERMINAL - female (16-14 ga) | 4 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 4 | ||
| 4 | 44-7330 | CONNECTOR - shroud (1-pin) | 1 | |
| 41-5243 | TERMINAL - fingrip (14-16 ga) | 1 | ||
| 5 | 44-5835 | CONNECTOR - shroud (2-pin) | 1 | |
| 44-5883 | TERMINAL - male (20-18 ga) | 1 | ||
| 44-5836 | TERMINAL - male (16-14 ga) | 1 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 1 | ||
| 44-5837 | SEAL - cable (gray, 14-16 ga) | 1 |
