Установкa Thermo King X500 AP схема INSTALLATION COMPONENTS – 260H9
Обновление от: 7/17/12
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 66-1273 | VALVE - check (hose) | A/R |
| 2 | 61-5601 | HOSE (16mm id, 40m long) | A/R |
| 61-5417 | HOSE (16mm id, 16m long) | A/R | |
| 3 | 55-6726 | CLAMP - hose | A/R |
| 4 | 203-391 | SEALER - tape | A/R |
| 5 | 55-2330 | BANDWRAP (1.75 dia) | A/R |
| 6 | 55-8542 | WASHER - special | A/R |
| 7 | 55-6349 | TEE - drain hose | 2 |
| 8 | 33-3191 | GASKET - flange | A/R |
| 9 | 203-515 | OIL - solest 120 (1L) | A/R |
| 10 | 203-505 | OIL - compressor POE (8 oz) | A/R |
