Установкa Thermo King X500 AP схема SmartAIRE DRIVER PANEL – 260H8
Обновление от: 1/20/13
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 41-6998 | SmartAIRE | 1 |
| 2 | 41-9199 | HARNESS - unit to connector (12M) | 1 |
| 41-9777 | HARNESS - unit to connector (12.5M) | 1 | |
| 41-8532 | HARNESS - unit to connector (14M) | 1 | |
| 41-8533 | HARNESS - unit to connector (16M) | 1 | |
| 42-661 | HARNESS - unit to connector (16M) | 1 | |
| 41-4604 | HARNESS - unit to connector (18.3M) | 1 | |
| 3 | 41-661 | CONNECTOR - 14-pin | 1 |
| 41-1807 | SOCKET (18-24 ga) | 14 | |
| 4 | 44-6381 | CONNECTOR - female (1-pin) | 1 |
| 44-5066 | TERMINAL - fingrip | 1 | |
| 5 | 41-8534 | CONNECTOR - 6-pin | 1 |
| 41-8513 | TERMINAL - male | 6 | |
| 41-8514 | SEAL | 6 | |
| 6 | 41-8509 | CONNECTOR - 9-pin | 1 |
| 41-8513 | TERMINAL - male | 9 | |
| 41-8514 | SEAL | 9 |
