Установкa Thermo King X1000 AP схема HEATER COMPONENTS W/ COOLANT VALVE – 268D8
Обновление от: 2/19/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2825 | COIL - evaporator, w/ heat | 1 | |
| 2 | 67-2826 | COIL - evaporator, w/ heat | 1 | |
| 3 | 61-6417 | TUBE - outlet, coolant | 1 | |
| 4 | 61-6415 | TUBE - inlet, coolant | 1 | |
| 5 | 55-3401 | CLAMP | 4 | |
| 6 | 92-5032 | HOSE | 2 | |
| 7 | 41-9943 | VALVE - coolant | 1 | |
| 8 | 41-6767 | CONTROLER - servomotor, valve | 1 | |
| 9 | 61-6416 | ADAPTER - tube, coolant | 1 | |
| 10 | 93-758 | BRACKET - coolant tubes | 1 | |
| 55-5130 | RIVET - bracket | 4 | ||
| 11 | 55-7013 | CLAMP - tube | 2 | |
| 55-8993 | SCREW - clamp | 2 | ||
| 55-6996 | LOCKWASHER | 2 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 12 | 33-452 | GROMMET | 1 | |
| 13 | 12-822 | PUMP - coolant (optional) | 1 | |
| 14 | 61-2182 | HOSE - connection kit (optional, kit 720320) | 1 |
