Установкa Thermo King X1000 AP схема COMPRESSOR GROUP (1E17375G15, KIT 700835) – 262E6
Обновление от: 8/20/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-917 | COMPRESSOR - X430 C5 (subassy, see 228E5) | 1 | |
| 8102-917 | COMPRESSOR - X430 C5 (subassy reman, see 228E5) | 1 | ||
| 2 | 66-2140 | VALVE - discharge | 1 | |
| 66-3015 | CAP - service valve (brass, incl gasket) | 1 | ||
|
10-66-3015 | Крышка сервисного клапана, латунь, X426/430/640 | 3 000 ₽ |
|
| P-17-10806-10 | Крышка сервисного клапана, латунь, 05K/05G/06D | 3 000 ₽ |
|
|
| 33-350 | GASKET - cap | 1 | ||
| 3 | 55-201 | SCREW - valve to compressor | 2 | |
| 4 | 33-2805 | GASKET - discharge valve | 1 | |
|
33-2805 OEM | Прокладка коллектора армированная, X426/430 | 800 ₽ |
|
|
10-33-2805 | Прокладка коллектора армированная, X426/430 | 620 ₽ |
|
|
10-33-2546 | Прокладка коллектора, X426/430 | 340 ₽ |
|
|
PP-33-2805 | Прокладка коллектора, X426/430 | 50 ₽ |
|
| 5 | 55-308 | ELBOW | 2 | |
| 6 | 33-768 | GASKET | 2 | |
| 7 | 66-3576 | VALVE - suction | 1 | |
| 66-3015 | CAP - service valve (brass, incl gasket) | 1 | ||
| P-17-10806-10 | Крышка сервисного клапана, латунь, 05K/05G/06D | 3 000 ₽ |
|
|
|
|
10-66-3015 | Крышка сервисного клапана, латунь, X426/430/640 | 3 000 ₽ |
|
| 33-350 | GASKET - cap | 1 | ||
| 8 | 55-6776 | SCREW - valve to compressor | 2 | |
| 9 | 33-2541 | GASKET - suction valve | 1 | |
| 10 | 55-466 | ELBOW | 1 | |
| 11 | 55-895 | FLATWASHER | 2 | |
| 12 | 41-6795 | HARNESS - compressor (for connectors see 115D14) | 1 | |
| 13 | 41-4486 | SWITCH - hpco (R407c) | 1 | |
| 41-4809 | SWITCH - only | 1 | ||
| 14 | 41-4147 | SWITCH - lpco (for connector see 115D14) | 1 | |
| 41-4530 | SWITCH - only | 1 | ||
| 15 | 55-6804 | WASHER - sealing | 2 | |
| 16 | 55-5261 | CLAMP | 2 | |
| 17 | 55-433 | PLUG | 1 | |
| 18 | 55-1983 | CAP | 2 | |
| 19 | 92-5004 | NAMEPLATE - R407c | 1 | |
| 20 | 77-2938 | PULLEY - clutch (9K 226mm, 6K 238mm, see 233C5) | 1 | |
| 21 | 55-3451 | STUD - clutch to compressor | 3 | |
| 22 | 55-790 | LOCKWASHER | 3 | |
| 23 | 55-789 | NUT | 3 | |
| 24 | 77-1491 | SPACER | 1 | |
| 25 | 55-9088 | KEY - shaft | 1 |
