Установкa Thermo King X1000 AP схема CONDENSER REFRIGERATION COMPONENTS (LEFT SIDE IN/OUT) – 262E2
Обновление от: 2/19/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-6247 | TUBE - discharge | 1 | |
| 2 | 55-9186 | FLANGE | 1 | |
| 51-577 | ADAPTER | 1 | ||
| 3 | 66-2805 | FITTING - saddle | 1 | |
| 4 | 61-6245 | FITTING - saddle | 1 | |
| 5 | 93-317 | PLATE | 1 | |
| 6 | 67-2778 | COIL - condenser | 1 | |
| 55-6994 | SCREW - coil | 6 | ||
| 51-167 | FLATWASHER | 6 | ||
| 55-7042 | NUT | 6 | ||
| 7 | 33-5025 | STRIP - neoprene (1530 mm cut to length) | A/R | |
| 8 | 67-2779 | TANK - receiver | 1 | |
| 9 | 55-2688 | CLAMP | 3 | |
| 10 | 61-6246 | TUBE - outlet, receiver | 1 | |
| 11 | 66-4694 | VALVE - shutoff | 1 | |
| 12 | 61-6229 | TUBE - sightglass | 1 | |
| 55-6838 | NUT | 1 | ||
| 13 | 66-8344 | DEHYDRATOR | 1 | |
| 33-566 | O-RING | 2 | ||
| 14 | 61-6228 | TUBE - dehydrator | 1 | |
| 55-6838 | NUT | 1 | ||
| 15 | 66-1188 | INDICATOR - liquid | 1 | |
| 16 | 61-6230 | TUBE - sight glass | 1 | |
| 17 | 93-247 | BRACKET - suction/ discharge | 1 | |
| 18 | 92-8932 | BRACKET - flange | 1 | |
| 55-5427 | SCREW - bracket | 1 | ||
| 19 | 93-248 | BRACKET - tube | 1 | |
| 20 | 55-3065 | CLAMP - tube (.50 dia) | 1 | |
| 55-6994 | SCREW | 1 | ||
| 55-6996 | LOCKWASHER | 1 | ||
| 55-7075 | FLATWASHER | 1 | ||
| 21 | 66-7392 | VALVE - relief | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 22 | 41-5220 | SWITCH - hpco (703032, 703055, 703097, 703195 & 703197) | 1 | |
| 41-5781 | TRANSDUCER - discharge (703181 & 703193) | 1 | ||
| 41-5781 OEM | Трансдюсер, V-Series | 32 730 ₽ |
|
|
|
10-41-5781 | Трансдюсер, V-Series | 3 820 ₽ |
|
| 23 | 33-1213 | GROMMET (.50 id) | 1 | |
| 33-367 | GROMMET (.625 id) | 1 | ||
| 33-572 | GROMMET (.75 id) | 3 | ||
| 33-452 | GROMMET (.875 id) | 2 | ||
| 33-1770 | GROMMET (1.5 id) | 2 | ||
| 33-1371 | GROMMET (1.703 id) | 2 |
