Установкa Thermo King X1000 AP схема RETURN AIR GRILLE (703080) – 262B9
Обновление от: 7/30/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-9088 | FILTER - air | 1 | |
| 2 | 98-9089 | SCREEN - assembly | 1 | |
| 3 | 91-9638 | NAMEPLATE - TK | 1 | |
| 4 | 91-9343 | CLIP - filter | 1 | |
| 5 | 91-8903 | HINGE - frame | 3 | |
| 55-2012 | RIVET - hinge | 9 | ||
| 6 | 92-6407 | ANGLE - filter | 2 | |
| 55-2012 | RIVET - angle | 4 | ||
| 7 | 98-9090 | FRAME - assembly | 1 | |
| 8 | 55-2782 | SCREW - lock | 3 | |
| 9 | 55-7112 | LOCKWASHER | 3 | |
| 10 | 91-7625 | LOCKPLATE | 3 | |
| 55-3035 | RIVET - plate | 6 | ||
| 11 | 55-2074 | NUT - lock | 3 |
