Установкa Thermo King X1000 AP схема INSULATION – 262B0
Обновление от: 2/18/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-5009 | INSULATION (7.5M & 5M roof radius) | 2 | |
| 2 | 33-5010 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5091 | INSULATION (5M roof radius) | 1 | ||
| 3 | 33-5011 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5090 | INSULATION (5M roof radius) | 1 | ||
| 4 | 33-5012 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5085 | INSULATION (5M roof radius) | 1 | ||
| 5 | 33-5013 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5089 | INSULATION (5M roof radius) | 1 | ||
| 6 | 33-5014 | INSULATION (5M, 7M & 10M roof radius) | 1 | |
| 7 | 33-5015 | INSULATION (5M, 7M & 10M roof radius) | 1 | |
| 8 | 33-5016 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5084 | INSULATION (5M roof radius) | 1 | ||
| 9 | 33-5017 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5088 | INSULATION (5M roof radius) | 1 | ||
| 10 | 33-5018 | INSULATION (5M, 7M & 10M roof radius) | 1 | |
| 11 | 33-5019 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5086 | INSULATION (5M roof radius) | 1 | ||
| 12 | 33-5020 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5087 | INSULATION (5M roof radius) | 1 | ||
| 13 | 33-5021 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5081 | INSULATION (5M roof radius) | 1 | ||
| 14 | 33-5022 | INSULATION (7.5M & 10M roof radius) | 1 | |
| 33-5082 | INSULATION (5M roof radius) | 1 | ||
| 15 | 33-5023 | STRIP - neoprene (1200 mm cut to length) | A/R | |
| 16 | 33-5083 | INSULATION (5M roof radius) | 2 | |
| NSS | INSULATION (7.5M & 10M roof radius) | 2 |
