Установкa Thermo King V-800 Series DSR схема COMPRESSOR GROUP - QP21 – 270D5
Обновление от: 5/8/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-1088 | COMPRESSOR - QP21 (12V, 2A 145 dia) | 1 | |
| 10-TM-21 | Компрессор TM-21, 12V 2A | 28 910 ₽ |
|
|
| 102-1089 | COMPRESSOR - QP21 (24V, 2A 145 dia) | 1 | ||
|
10-TM-21-24 | Компрессор TM-21, 24V 2A | 28 910 ₽ |
|
| 102-1090 | COMPRESSOR - QP21 (12V, 8V 137 dia) | 1 | ||
| 10-TM-21-8 | Компрессор TM-21, 12V 8PK | 28 910 ₽ |
|
|
| 102-1091 | COMPRESSOR - QP21 (24V, 8V 137 dia) | 1 | ||
|
10-TM-21-8-24 | Компрессор TM-21, 24V 8PK | 28 910 ₽ |
|
| 203-513 | OIL - compressor (ester solest 35, 1 liter) | 1 | ||
| EN-203-513 | Масло компрессора, R134a / R404a | 2 200 ₽ |
|
|
| 44-7327 | CONNECTOR - tower (1-pin) | 1 | ||
| 44-5884 | TERMINAL - female (18-20 ga) | 1 | ||
| 2 | 22-1263 | FILTER - suction | 1 | |
| 3 | 22-1335 | KIT - manifold (90 degree swivel) | 1 | |
| 51-1652 | SCREW - manifold | 1 | ||
| 33-672 | O-RING | 2 | ||
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 4 | 92-1662 | NAMEPLATE - 12 V | 1 | |
| 92-2810 | NAMEPLATE - 24 V | 1 |
