Установкa Thermo King V-800 Series DSR схема EVAPORATOR ELECTRICAL (ES800) – 270D4
Обновление от: 9/11/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2480 | COIL - evaporator | 1 | |
| 55-8375 | NUT - captive | 19 | ||
| 2 | 98-8897 | COVER - evaporator | 1 | |
| 51-2010 | SCREW - cover | 9 | ||
| 55-9492 | WASHER - cosmetic | 2 | ||
| 55-9491 | CAP - cosmetic | 2 | ||
| 3 | 41-5784 | SENSOR - tempurature | 1 | |
| 42-3067 OEM | Датчик температуры, V-Series | 12 360 ₽ |
|
|
| 10-42-3067 | Датчик температуры, V-Series | 9 420 ₽ |
|
|
| 4 | 78-1713 | BLOWER - evaporator (12V) | 3 | |
| 78-1712 | BLOWER - evaporator (24V) | 3 | ||
| 10-78-1712 | Турбина испарителя, 24V, V-700/800 | 13 220 ₽ |
|
|
| 51-250 | SCREW - blower | 12 | ||
| 55-7861 | LOCKWASHER | 12 | ||
| 55-7697 | FLATWASHER | 12 | ||
| 5 | 92-9892 | PLATE - blower | 3 | |
| 6 | 92-9519 | GRILLE - blower | 3 | |
| 51-1808 | RIVET - grille (unscrewing, before May 13) | 9 | ||
| 51-2010 | SCREW - grille (May 13 & after) | 9 | ||
| 55-9826 | WASHER | 9 | ||
| 51-2012 | NUT | 9 | ||
| 7 | 33-2923 | GROMMET (35 mm) | 2 | |
| 8 | 41-9627 | HARNESS - drain tube heater (12V, for MAX units) | 1 | |
| 41-3156 | HARNESS - drain tube heater (24V, for MAX units) | 1 | ||
| 9 | 92-3466 | TUBE - drain | 2 | |
| 10 | 51-791 | WASHER (EPDM 26 od 16.5 id) | 2 | |
| 11 | 51-790 | NUT - tube | 2 |
