Установкa Thermo King V-700 MAX SPECTRUM схема EVAPORATOR GROUP (ES500) – 249G1
Обновление от: 3/8/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2478 | COIL - evaporator | 1 | |
| 2 | 61-1416 | FILTER - expansion valve | 1 | |
| 3 | 66-9314 | VALVE - expansion | 1 | |
|
66-9314 OEM | ТРВ, V/VM-Series MAX (R404A) | 31 890 ₽ |
|
| 4 | 41-5784 | SENSOR - temperature | 1 | |
| 42-3067 OEM | Датчик температуры, V-Series | 12 360 ₽ |
|
|
| 10-42-3067 | Датчик температуры, V-Series | 9 420 ₽ |
|
|
| 55-9825 | CLAMP - sensor | 1 | ||
| 51-2010 | SCREW - clamp | 1 | ||
| 5 | 41-3136 | SWITCH - defrost termination | 1 | |
| 51-2071 | SCREW - switch | 2 | ||
| 6 | 78-1374 | FAN - evaporator (24V) | 3 | |
| 10-78-1374 | Вентилятор испарителя 24V, V/C-Series | 9 820 ₽ |
|
|
|
PP-78-1374 | Вентилятор испарителя 24V, V/C-Series | 5 670 ₽ |
|
| 51-1808 | RIVET - fan | 12 | ||
| 7 | 33-3135 | GROMMET (35 mm) | 1 | |
| 8 | 98-8289 | COVER - evaporator (injection molded) | 1 | |
| 51-2010 | SCREW - cover | 8 | ||
| 55-9492 | WASHER - cosmetic | 2 | ||
| 55-9492 | WASHER - cosmetic | 2 | ||
| 55-9491 | CAP - cosmetic | 2 | ||
| 9 | 41-3156 | HARNESS - drain tube heater (24V) | 2 | |
| 10 | 92-3466 | TUBE - drain | 2 | |
| 11 | 51-791 | WASHER - tube | 2 | |
| 12 | 51-790 | NUT - tube | 2 | |
| 13 | 61-434 | FITTING (#6) | 2 | |
| 55-9836 | NUT (#6) | 2 | ||
| 14 | 61-5473 | TUBE - fitting to valve | 1 | |
| 15 | 66-7878 | SOLENOID - base | 2 | |
| 51-2103 | SCREW - solenoid | 1 | ||
| 16 | 41-5791 | COIL - valve (24V) | 2 | |
|
10-41-5791 | Катушка соленоида 24V, V-Series | 4 200 ₽ |
|
| 204-1074 | TOOL - coil magnet | 1 | ||
| 17 | 92-8857 | BRACKET - solenoid | 1 | |
| 55-2260 | RIVET - bracket | 4 | ||
| 18 | 33-1015 | O-RING (#6) | 2 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 19 | 67-2615 | HEAT EXCHANGER (includes item 13,15, 20 & 21) | 1 | |
| 20 | 51-344 | NUT | 1 | |
| 21 | 51-2102 | NUT - adapter (#12) | 1 | |
| 51-808 | NUT - fitting (#12) | 1 | ||
| 22 | 33-1222 | O-RING (#12) | 1 | |
| 23 | 92-8858 | BRACKET - fittings | 1 | |
| 24 | 92-1502 | CLAMP | 1 | |
| 51-2012 | NUT - clamp | 1 | ||
| 41-5784 | SENSOR - temperature | 1 | ||
| 42-3067 OEM | Датчик температуры, V-Series | 12 360 ₽ |
|
|
| 10-42-3067 | Датчик температуры, V-Series | 9 420 ₽ |
|
