Установкa Thermo King V-700 MAX SPECTRUM схема V-700 MAX SPECTRUM REFERENCE SHEET – 16U19
Обновление от: 1/14/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 901788 | V-700 MAX 50 SPECTRUM | 12/10 | ||
| 700031 | Undermount Kit | 1/11 | ||
| 702032 | Compressor Kit - TK 315R 24V | 1/11 | ||
| 702156 | Receptacle & Plug 4-pole | 1/11 | ||
| 702157 | Receptacle & Plug 5-pole | 1/11 | ||
| 702536 | Condenser - V-700 MAX 50 Without Bypass Valve | 1/11 | ||
| 702537 | Condenser - V-700 MAX 50 With Bypass Valve | 1/11 | ||
| 702538 | Evaporator 2X ES400 Configuration | 1/11 | ||
| 702539 | Evaporator ES400 R404a Multi Temp | 1/11 | ||
| 702540 | Installation Kit | 1/11 | ||
| 702541 | Evaporator ES500 + ES150 Configuration | 1/11 | ||
| 702542 | ES500 Evaporator R404a Multi Temp | 1/11 | ||
| 702543 | ES150 Evaporator R404a Multi Temp | 1/11 | ||
| 702544 | Installation Kit | 1/11 | ||
| 702545 | Evaporator ES500 + 2X ES150 Configuration | 1/11 | ||
| 702546 | Evaporator 2X ES150 R404a Multi Temp | 1/11 | ||
| 702547 | Installation Kit | 1/11 | ||
| 702548 | Hose Kit | 1/11 | ||
| 702549 | Hose Kit | 1/11 | ||
| 720782 | Hose Cover Kit | 12/10 | ||
| 720818 | DIN Adapter | 12/10 | ||
| 720837 | Door Switch Kit | 12/10 |
