Установкa Thermo King V-520 схема HEATER COIL AND PUMP GROUP – 233C7
Обновление от: 2/20/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-5823 | BRACKET - pump & valve | 1 | |
| 2 | 41-2233 | PUMP - water (12V) | 1 | |
| 41-9326 | HARNESS - pump | 1 | ||
| 55-7172 | SCREW - pump | 2 | ||
| 55-7170 | LOCKWASHER | 2 | ||
| 55-7075 | FLATWASHER | 2 | ||
| 55-7042 | NUT | 2 | ||
| 3 | 98-796 | HOSE - water | 1 | |
| 4 | 55-6726 | CLAMP - hose | 2 | |
| 5 | 61-3507 | VALVE - water (12VDC) | 1 | |
| 55-7075 | SCREW - valve | 2 | ||
| 55-7404 | LOCKWASHER | 2 | ||
| 55-7089 | FLATWASHER | 4 | ||
| 6 | 41-8539 | HARNESS - pump | 1 | |
| 7 | 44-5835 | CONNECTOR - shroud (2-pin) | 2 | |
| 8 | 44-5838 | CONNECTOR - tower (2-pin) | 1 | |
| 9 | 67-2099 | COIL - heater (water) | 1 | |
| 66-4139 | FITTING - saddle | 1 | ||
| 11-7777 | INSERT - valve | 1 | ||
| 55-5672 | CAP - valve | 1 | ||
| 11 | 41-6492 | HEATER (230V) | 1 | |
| 12 | 91-240 | RETAINER - heater | 8 | |
| 13 | 98-7045 | GRILLE - heater coil | 1 | |
| 14 | 41-6531 | SWITCH - limit | 1 | |
| 15 | 41-6491 | HARNESS - heater & switch | 1 |
