Установкa Thermo King V-520 схема V-520 REFERENCE SHEET – 13U32
Обновление от: 5/27/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 900829 | System V-520 10 | 5/12 | ||
| 900830 | System V-520 20 | 12/09 | ||
| 900831 | System V-520 10 MAX | 12/09 | ||
| 900833 | System V-520 20 MAX | 5/12 | ||
| 902041 | System V-520 30 | 12/11 | ||
| 902053 | System V-520 MAX 30 | 12/11 | ||
| 902049 | System V-520 50 | 12/11 | ||
| 902054 | System V-520 MAX 50 | 5/12 | ||
| 701425 | Evaporator V-520 | 5/12 | ||
| 701426 | Evaporator V-520 MAX | 5/12 | ||
| 701419 | Condenser V-520 10 | 5/12 | ||
| 701420 | Condenser V-520 20 | 12/09 | ||
| 701421 | Condenser V-520 10 MAX | 12/09 | ||
| 701422 | Condenser V-520 20 MAX | 5/12 | ||
| 702784 | Condenser V-520 30 | 12/11 | ||
| 702873 | Condenser V-520 30 MAX | 12/11 | ||
| 702758 | Condenser V-520 50 | 12/11 | ||
| 702874 | Condenser V-520 50 MAX | 5/12 | ||
| 700893 | Hose Kit - V500 | 5/12 | ||
| 701454 | 230/1/60 | 5/12 | ||
| 701455 | 230/3/60 | 5/12 | ||
| 700310 | Compressor TK312R 2A 12V | 5/12 | ||
| 700311 | Compressor TK312R Poly-8 12V | 5/12 | ||
| 701445 | Compressor TM16-XD Poly groove 12V | 10/11 | ||
| 701497 | Compressor TK-208R 2A 24V | 5/12 | ||
| 701498 | Compressor TK-208R Poly-8 24V | 5/12 | ||
| 701936 | Compressor TM16-DM Poly groove 12V | 10/11 | ||
| 719972 | Compressor TM16-XD 2A 12V | 10/11 | ||
| 719973 | Compressor TM16-XD 2A 24V | 10/11 | ||
| 719974 | Compressor TM15-XD 2A 12V | 10/11 | ||
| 719975 | Compressor TM15-XD 2A 12V | 10/11 | ||
| 719976 | Compressor TM13-XD 2A 12V | 10/11 | ||
| 719977 | Compressor TM13-XD 2A 24V | 10/11 | ||
| 719978 | Compressor TM13-XD Poly groove | 10/11 | ||
| 719979 | Compressor TM13-XD Poly groove | 10/11 | ||
| 719980 | Compressor TM15-XD Poly groove | 10/11 | ||
| 719981 | Compressor TM15-XD Poly groove | 10/11 | ||
| 719982 | Compressor TM16-XD Varia-groove | 10/11 | ||
| 719983 | Compressor TM16 XD Varia-groove | 10/11 | ||
| 719984 | Compressor TM13-HA 12V | 10/11 | ||
| 719986 | Compressor TM15-XD Varia-groove | 10/11 | ||
| 701444 | Water Heat V-520 10 | 5/12 | ||
| 701446 | Water/Electric Heat 12V | 5/12 | ||
| 701448 | 24V V-520 10 | 5/12 | ||
| 701449 | 24V V-520 10 MAX | 12/09 | ||
| 701624 | 24V V-520 20 | 12/09 | ||
| 701625 | 24V V-520 20 MAX | 5/12 | ||
| 701644 | 400/3/60 V520 | 12/09 | ||
| 701645 | 400/3/50 V520 | 12/09 | ||
| 702123 | Compressor TK-312R 24V | 5/12 | ||
| 702201 | Compressor TM16-HD DM 12V | 5/12 | ||
| 702202 | Compressor TM16-HD DM 24V | 10/11 | ||
| 702203 | Compressor TM16-HD DM 12V | 10/11 | ||
| 702204 | Compressor TM16-HD DM 24V | 10/11 | ||
| 702751 | Accumulator | 5/12 | ||
| 702823 | Compressor TM16-XD 12V PV8 119 mm | 5/12 | ||
| 702824 | Compressor TM16-XD 12VDC PV8 | 5/12 | ||
| 702825 | Compressor TM16-XD 12V 2A 135 MM | 5/12 | ||
| 702826 | Compressor TM15-XD 12V 2A 135 MM | 5/12 | ||
| 702827 | Compressor 13XD 12V 2A 135D MM | 5/12 | ||
| 702828 | Compressor 13XD 12V PV8 120 MM | 5/12 | ||
| 702829 | Compressor TM15-XD 12V PV8 120 MM | 5/12 | ||
| 702830 | Compressor TM16-XD 12VDC 1A/1B 135 MM | 5/12 | ||
| 702832 | Compressor TM15-XD 12V VG 159 MM | 5/12 | ||
| 702923 | Compressor TM16-XD 24V 2A 135 MM | 5/12 | ||
| 702926 | Compressor TM16-XD 24V PV8 | 5/12 | ||
| 702927 | Compressor TM16-HD DM 12VDC 2A 1 | 5/12 | ||
| 702928 | Compressor TM16-HD DM 24VDC 2A 1 | 5/12 | ||
| 720466 | Compressor TK-208R 2A 12V | 5/12 | ||
| 720467 | Compressor TK-208R Poly-8 12V | 5/12 | ||
| 720837 | Door Switch | 5/12 | ||
| 800319 | Installation Kit | 5/12 |
